GAS BBQ GRILL USER'S MANUAL
MODEL NUMBER: PG-4020200LA
CUSTOMER SERVICE: (888)-287-0735
DANGER
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
Open lid.
4.
If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
FOR OUTDOOR USE ONLY
WARNING
1.
Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2.
An LP cylinder not connected for use
TM
shall not be stored in the vicinity of this
or any other appliance.
