  • Page 1 Network Camera User Manual...
  • Page 2 INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
  • Page 3 Network Camera User Manual Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Indicates a hazardous situation which, if not avoided, will or could result in death or DANGER serious injury. Indicates a potentially hazardous situation which, if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected CAUTION results.
  • Page 4 Network Camera User Manual • A few device components (e.g., electrolytic capacitor) require regular replacement. The average lifespan varies, so periodic checking is recommended. Contact your dealer for details. Usage Environment • Make sure the running environment meets the requirement of the device. The operating temperature shall be -30°...

  • Page 5: Table Of Contents

    Network Camera User Manual Contents Chapter 1 System Requirements ........................12 Chapter 2 Device Activation and Accessing ....................13 2.1 Activate the Device via SADP ........................13 2.2 Activate the Device via Browser ......................... 13 2.3 Login ................................14 2.3.1 Plug-in Installation ......................... 14 2.3.2 Admin Password Recovery ......................
  • Page 6 Network Camera User Manual 4.1.6 Frame Rate ............................23 4.1.7 Video Encoding ..........................23 4.1.8 Smoothing ............................25 4.2 ROI ................................25 4.2.1 Set ROI .............................. 25 4.2.2 Set Face Tracking ROI ........................26 4.2.3 Set Target Tracking ROI ........................26 4.2.4 Set License Plate Tracking ROI .......................
  • Page 7 Network Camera User Manual 5.2 Video Recording ............................37 5.2.1 Record Automatically ........................37 5.2.2 Record Manually ..........................38 5.2.3 Set Lite Storage ..........................39 5.2.4 Playback and Download Video ....................... 39 5.3 Capture Configuration ..........................40 5.3.1 Capture Automatically ........................40 5.3.2 Capture Manually ..........................
  • Page 8 Network Camera User Manual Chapter 7 Network Settings ..........................56 7.1 TCP/IP................................56 7.1.1 Multicast ............................56 7.1.2 Multicast Discovery ......................... 57 7.2 SNMP ................................57 7.3 Set SRTP ............................... 57 7.4 Port Mapping ..............................58 7.4.1 Set Auto Port Mapping ........................58 7.4.2 Set Manual Port Mapping ........................
  • Page 9 Network Camera User Manual Chapter 9 System and Security ........................76 9.1 View Device Information ..........................76 9.2 Search and Manage Log ..........................76 9.3 Simultaneous Login ............................ 76 9.4 Import and Export Configuration File ......................76 9.5 Export Diagnose Information ........................76 9.6 Reboot .................................
  • Page 10 Network Camera User Manual 9.15.6 Enable Certificate Expiration Alarm ....................85 9.16 User and Account ............................85 9.16.1 Set User Account and Permission ....................85 9.16.2 Simultaneous Login ........................86 9.16.3 Online Users ............................. 86 Chapter 10 Allocate VCA Resource ......................... 87 10.1 Face Capture ...............................
  • Page 11 Network Camera User Manual 10.7 Hard Hat Detection ............................ 101 10.7.1 Set Hard Hat Detection ......................... 102 10.8 Face Comparison and Modeling ....................... 102 10.8.1 Face Comparison .......................... 102 10.8.2 Face Modeling ..........................105 Chapter 11 Open Platform ..........................106 11.1 Set Open Platform .............................

  • Page 12: Chapter 1 System Requirements

    Network Camera User Manual Chapter 1 System Requirements Your computer should meet the requirements for proper visiting and operating the product. • Operating System: Microsoft Windows XP SP1 and above version CPU: • 2.0 GHz or higher RAM: • 1 GB or higher •...

  • Page 13: Chapter 2 Device Activation And Accessing

    2.1 Activate the Device via SADP Search and activate the online devices via SADP software. Before You Start Access www.hikvision.com to download the SADP software to install. Steps 1. Connect the device to a network using the network cable. 2. Run SADP software to search for online devices.

  • Page 14: Login

    Network Camera User Manual set the IP address of the PC to 192.168.1.100. 3. Input 192.168.1.64 in the browser. 4. Set device activation password. STRONG PASSWORD RECOMMENDED − We highly recommend that you create a strong password of your own choosing (using a minimum of eight characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 15: Admin Password Recovery

    Network Camera User Manual 2.3.2 Admin Password Recovery If you forget the admin password, you can reset the password by clicking Forget Password on the login page after completing the account security settings. You can reset the password by setting the security question or e-mail. NOTE: If you need to reset the password, make sure that the device and the PC are on the same network segment.

  • Page 16: Chapter 3 Live View

    Network Camera User Manual Chapter 3 Live View This chapter introduces the live view parameters, function icons, and transmission parameters settings. 2.4 Live View Parameters Supported functions vary by model. 2.4.1 Enable and Disable Live View This function quickly enables or disables live view of all channels. •...

  • Page 17: Window Division

    Network Camera User Manual NOTE: When you access the device via Internet Explorer, select Webcomponents or QuickTime. When you access the device via other browsers, select Webcomponents, QuickTime, VLC, or MJPEG. 2.4.5 Window Division • refers to 1 × 1 window division. •...

  • Page 18: Lens Initialization

    Network Camera User Manual If auxiliary focus cannot help the device focus clearly, use manual focus. 2.4.10 Lens Initialization Lens initialization is used on devices equipped with a motorized lens. This function can reset the lens when long time zoom or focus results in a blurred image. This function varies by model. Manual Lens Initialization Click to operate lens initialization.

  • Page 19: Conduct 3D Positioning

    Network Camera User Manual PTZ Speed • ­ Slide to adjust the speed of the pan/tilt movement. • Iris ­ When the image is too dark, click to enlarge the iris. ­ When the image is too bright, click to stop down the iris. 2.4.13 Conduct 3D Positioning 3D positioning relocates the selected area to the image center.

  • Page 20: Set Smooth Streaming

    Network Camera User Manual address for them before selection. Multicast NOTE: For detailed multicast information, refer to • HTTP HTTP is suitable for situations in which the third-party needs to get the stream from the device. Play Performance • ­ Shortest Delay: The device takes the real-time video image as priority over video fluency.
  • Page 21 Network Camera User Manual • Error Correction: The resolution and bitrate stay the same as the values set on the Video page. The mode corrects the data error during transmission to ensure the image quality. You can set the Error Correction Proportion within the range of 0–100.

  • Page 22: Chapter 4 Video And Audio

    Network Camera User Manual Chapter 4 Video and Audio This chapter introduces configuring video and audio related parameters. 4.1 Video Settings This section introduces setting video parameters such as stream type, video encoding, and resolution. Go to the setting page: Configuration → Video/Audio → Video. 4.1.1 Stream Type For devices that support more than one stream, you can specify parameters for each stream type.

  • Page 23: Video Type

    Network Camera User Manual 4.1.2 Video Type Select the content (video and audio) that should be contained in the stream. Video Only video content is contained in the stream. Video & Audio Video content and audio content are contained in the composite stream. 4.1.3 Resolution Select video resolution according to actual needs.
  • Page 24 Network Camera User Manual estimate the HDD consumption by its maximum average bitrate. Compared to H.264, H.264+ reduces storage by up to 50 percent with the same maximum bitrate in most scenes. When H.264+ is enabled, Max. Average Bitrate is configurable. The device uses a recommended maximum average bitrate by default.

  • Page 25: Smoothing

    Network Camera User Manual MJPEG • Motion JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding technology is used. Images in a MJPEG format are compressed as individual JPEG images. Profile • This function means that under the same bitrate, the more complex the profile, the higher the quality of the image, and the requirement for network bandwidth is also higher.

  • Page 26: Set Face Tracking Roi

    Network Camera User Manual 7. Optional: Select another region no. and repeat the above steps if you need to draw multiple fixed regions. 4.2.2 Set Face Tracking ROI When face tracking function is enabled in ROI and the face appears in the live picture, the image of the face is clearer than that of the surrounding area.

  • Page 27: Display Info. On Stream

    Network Camera User Manual NOTE: ROI level means the image quality enhancing level. The larger the value, the better the image quality. 4. Click Save. 4.3 Display Info. on Stream The objects’ (e.g., human, vehicle, etc.) information is marked in the video stream. You can set rules on the connected rear-end device or client software to detect events including line crossing, intrusion, etc.

  • Page 28: Two-Way Audio

    Network Camera User Manual 4.5 Two-way Audio Realizes the two-way audio function between the monitoring center and the target in the monitoring screen. Before You Start • Make sure the audio input device (pick-up or microphone) and audio output device (speaker) connected to the device is working properly.

  • Page 29: Focus Mode

    Network Camera User Manual 4.6.2 Focus Mode • Auto The device focuses automatically as the scene changes. If you cannot get a well-focused image under auto mode, reduce light sources in the image and avoid flashing lights. • Semi-auto The device focuses once after the PTZ and lens zooming. If the image is clear, the focus does not change when the scene changes.
  • Page 30 Network Camera User Manual NOTE: This function is supported only by certain devices equipped with a motorized lens. The image edge will be lost if this function is enabled. • If you focus on an object against a strong backlight, the object will be too dark to be seen clearly. BLC (backlight compensation) compensates light to the object in the front to make it clear.

  • Page 31: Image Parameters Switch

    Network Camera User Manual show the image normally. Select the mirror mode as needed. NOTE: The video recording will be shortly interrupted when the function is enabled. 4.6.3 Image Parameters Switch The device automatically switches image parameters in set time periods. Go to the image parameters switch setting page: Configuration →...

  • Page 32: Set Privacy Mask

    Network Camera User Manual Displayed Information • Set camera name, date, week, and their related display format. Text Overlay • Set customized overlay text on image. • OSD Parameters Set OSD parameters such as Display Mode, OSD Size, Font Color, and Alignment. 4.8 Set Privacy Mask The function blocks certain areas in the live view to protect privacy.

  • Page 33: Set Target Cropping

    Network Camera User Manual 5. Click Save. 4.10 Set Target Cropping You can crop the image, transmit and save only the images of the target area to save transmission bandwidth and storage. Steps 1. Go to Configuration → Video/Audio → Target Cropping. 2.

  • Page 34: Chapter 5 Video Recording And Picture Capture

    4. Click Save. 5.1.2 Detect Memory Card Status Detects the status of a Hikvision memory card, and receive notifications when your memory card is detected to be abnormal. Before You Start Install a memory card in the device.

  • Page 35: Unlock

    Network Camera User Manual • Health Status: The condition of the memory card. There are three status descriptions, good, bad, and damaged. You will receive a notification if the health status is anything other than good when the Arming Schedule and Linkage Method are set. NOTE: Change the memory card when the health status is not “good.”...

  • Page 36: Set Nas

    Network Camera User Manual 2. Configure FTP settings. • FTP Protocol: FTP and SFTP are selectable. The files uploading is encrypted by using SFTP protocol. • Server Address and Port: The FTP server address and corresponding port. • User Name and Password: The FTP user should have permission to upload pictures. NOTE: If the FTP server supports picture uploading by anonymous users, you can check Anonymous to hide your device information during uploading.

  • Page 37: Emmc Protection

    Network Camera User Manual 4. Click Test to check whether the network disk is available. 5. Click Save. 5.1.6 eMMC Protection If you enable eMMC protection, the lifespan of the eMMC is displayed. 5.1.7 Set Cloud Storage It helps to upload the captured pictures and data to the cloud. The platform requests picture directly from the cloud for picture and analysis.

  • Page 38: Record Manually

    Network Camera User Manual Steps 1. Go to Configuration → Storage → Schedule Settings → Record Schedule. 2. Check Enable. 3. Select a record type. NOTE: The record type varies by model. • Continuous: The video will be recorded continuously according to the schedule. •...

  • Page 39: Set Lite Storage

    Network Camera User Manual 2. Set the Record File Size and saving path to for recorded files. 3. Click Save. 4. Click to start recording. Click to stop recording. 5.2.3 Set Lite Storage After lite storage is enabled, the frame rate and bitrate of the video stream can be reduced to lengthen the storage time of the memory card when there is no moving object in the monitoring scenario.

  • Page 40: Capture Configuration

    Network Camera User Manual 1) Set the search condition and click Search. 2) Select the video files and then click Download. NOTE: Go to Configuration → Local, and click Save downloaded files to to change the saving path of downloaded video files. 5.3 Capture Configuration The device can capture the pictures manually or automatically and save them in the configured saving path.

  • Page 41: View And Download Picture

    Network Camera User Manual 5.3.3 View and Download Picture You can search, view and download the pictures stored in the local storage or network storage. Steps 1. Click Picture. 2. Set search condition and click Search. The matched pictures show in the file list. 3.

  • Page 42: Chapter 6 Event And Alarm

    Network Camera User Manual Chapter 6 Event and Alarm This chapter introduces configuring events. The device takes certain responses to triggered alarms. 6.1 Basic Event 6.1.1 Set Motion Detection Detects moving objects in the detection region and triggers linkage actions. Steps 1.

  • Page 43: Normal Mode

    Network Camera User Manual ­ Day/Night Scheduled-Switch: The system switches day/night mode according to the schedule. It switches to day mode during the set periods and switches to night mode during the other periods. • Sensitivity: The higher the sensitivity value, the more sensitive the motion detection. If the sensitivity is set to , motion detection and dynamic analysis do not take effect.

  • Page 44: Set Video Tampering Alarm

    Network Camera User Manual Figure 2, Set Rules • Stop Drawing: Stop drawing one area. • Clear All: Clear all the areas. 4. Optional: You can set the parameters of multiple areas by repeating the above steps. 6.1.4 Set Video Tampering Alarm When the configured area is covered and cannot be monitored normally, the alarm is triggered and the device takes certain alarm response actions.

  • Page 45: Set Pir Alarm

    Network Camera User Manual Figure 3, Set Video Tampering Area Set Arming Schedule Linkage Method Settings 5. Refer to for setting scheduled time. Refer to for setting linkage method. 6. Click Save. 6.1.5 Set PIR Alarm A PIR (Passive Infrared) alarm is triggered when an intruder moves within the detector’s field of view. The heat energy dissipated by a person, or any other warm blooded creature such as a dog, cat, etc., can be detected.

  • Page 46: Set Alarm Input

    Network Camera User Manual Steps 1. Go to Configuration → Event → Basic Event → Exception. 2. Select Exception Type. • HDD Full: The HDD storage is full. • HDD Error: Error occurs in HDD. • Network Disconnected: The device is offline. •...

  • Page 47: Set Vibration Detection

    Network Camera User Manual 3. Set the corresponding parameters. Alarm Detection Interval The time interval to detect the exception. Sensitivity The higher the value, the more easily the exception will be detected, and the higher the possibility of misinformation. Alarm Delay Times The device uploads the alarm when the alarm reaches the set number of times.

  • Page 48: Detect Audio Exception

    Network Camera User Manual 6.2.1 Detect Audio Exception Audio Exception Detection detects abnormal sound in the surveillance scene such as the sudden increase/decrease in sound intensity, and certain actions can be taken in response. Steps 1. Go to Configuration → Event → Smart Event → Audio Exception Detection. 2.

  • Page 49: Detect Scene Change

    Network Camera User Manual 6.2.3 Detect Scene Change Scene Change Detection detects change in the surveillance scene. Certain actions can be taken when an alarm is triggered. Steps 1. Go to Configuration → Event → Smart Event → Scene Change Detection. 2.

  • Page 50: Set Intrusion Detection

    Network Camera User Manual Set Arming Schedule Linkage Method Settings 3. Refer to for setting scheduled time. Refer to for setting linkage method. 4. Click Save. 6.2.6 Set Intrusion Detection Detects objects entering and loitering in a pre-defined virtual region. If it occurs, the device can take linkage actions.

  • Page 51: Set Line Crossing Detection

    Network Camera User Manual 7. Click Save. 6.2.7 Set Line Crossing Detection Detects objects crossing a pre-defined virtual line. If it occurs, the device can take linkage actions. Steps 1. Go to Configuration → Event → Smart Event → Line Crossing Detection. 2.

  • Page 52: Set Region Entrance Detection

    Network Camera User Manual Set Arming Schedule 7. For the arming schedule settings, refer to . For the linkage method settings, refer Linkage Method Settings 8. Click Save. 6.2.8 Set Region Entrance Detection Detects objects entering a pre-defined virtual region. If it occurs, the device can take linkage actions. Steps 1.

  • Page 53: Set Unattended Baggage Detection

    Network Camera User Manual 3. Select one Region. For the detection region settings, refer to Draw Area 4. Select the detection target. Human and vehicle are available. If the detection target is not selected, all the detected targets will be reported, including humans and vehicles. Figure 7, Set Rule 5.

  • Page 54: Set Object Removal Detection

    Network Camera User Manual Figure 8, Set Rule 5. Optional: You can set the parameters of multiple areas by repeating the above steps. Set Arming Schedule 6. For the arming schedule settings, refer to . For the linkage method settings, refer Linkage Method Settings 7.

  • Page 55: Draw Area

    Network Camera User Manual Figure 9, Set Rule 5. Optional: Repeat the above steps to set more regions. Set Arming Schedule 6. For the arming schedule settings, see . For the linkage method settings, see Linkage Method Settings Click Save. NOTE: The function is supported only by certain models.

  • Page 56: Chapter 7 Network Settings

    Network Camera User Manual Chapter 7 Network Settings 7.1 TCP/IP TCP/IP settings must be properly configured before you can operate the device over a network. IPv4 and IPv6 are both supported. Both versions can be configured simultaneously without conflicting with each other.

  • Page 57: Multicast Discovery

    Network Camera User Manual IP Address: It stands for the address of multicast host • • Stream Type: The stream type of the multicast source • Video Port: The video port of the selected stream Audio Port: The audio port of the selected stream •...

  • Page 58: Port Mapping

    Network Camera User Manual 2. Select Server Certificate. 3. Select Encrypted Algorithm. 4. Click Save. NOTE: Only certain device models support this function. If the function is abnormal, check if the selected certificate is abnormal in certificate management. 7.4 Port Mapping By setting port mapping, you can access devices through the specified port.

  • Page 59: Set Port Mapping On Router

    Network Camera User Manual What To Do Next Go to the router port mapping settings interface and set the port number and IP address to be the same as those on the device. For more information, refer to the router user manual. 7.4.3 Set Port Mapping on Router The following settings are for a specific router.

  • Page 60: Access To Device Via Domain Name

    Network Camera User Manual HTTP Port: The port through which the browser accesses the device. For example, when the HTTP Port • http://192.168.1.64:81 is modified to 81, enter in the browser for login. HTTPS Port: The port through which the browser accesses the device with a certificate. Certificate •...

  • Page 61: Access To Device Via Pppoe Dial Up Connection

    Network Camera User Manual • By Browsers: Enter the domain name in the browser address bar to access the device. • By Client Software: Add domain name to the client software. Refer to the client manual for specific adding methods. 7.7 Access to Device via PPPoE Dial Up Connection This device supports the PPPoE auto dial-up function.

  • Page 62: Set White List

    Network Camera User Manual Steps 1. Go to Configuration → Network → Advanced Settings → Wireless Dial. 2. Check to enable the function. 3. Click Dial Parameters to configure and save the parameters. 4. Click Dial Plan. See Set Arming Schedule for detailed information.

  • Page 63: Wi-Fi

    Network Camera User Manual • Delete the white list that already set. • Send Test SMS Send a message to the mobile phone for test. 5. Click Save. 7.9 Wi-Fi Connect the device to a wireless network by setting Wi-Fi parameters. This function is supported only by certain device models.
  • Page 64 Network Camera User Manual Before You Start Complete the operation within 120 seconds, otherwise the connection will fail. Steps 1. Go to the TCP/IP settings page: Configuration → Network → Basic Configuration → TCP/IP. TCP/IP 2. Select Wlan to set the parameters. Refer to for detailed configuration.
  • Page 65 Network Camera User Manual NOTE: For stable use of Wi-Fi, it is not recommended to use DHCP. 3. Go to the Wi-Fi setting page: Configuration → Network → Advanced Configuration → Wi-Fi. 4. Check Enable WPS. 5. Click Generate to generate a device PIN code. 6.

  • Page 66: Set Network Service

    Network Camera User Manual 7.10 Set Network Service You can control the ON/OFF status of certain protocols as desired. Steps NOTE: This function varies by model. Go to Configuration → Network → Advanced Settings → Network Service. 1. Set network service. •...

  • Page 67: Set Alarm Server

    • Visit the official site of our company. Then go to Support → Tools → Hikvision App Store. Scan the QR code below to download the application. 2. If errors such as “Unknown app” occur during the installation, solve the problem in two ways.

  • Page 68: Enable Hik-Connect Service On Camera

    Network Camera User Manual • https://appstore.hikvision.com/ , and click Installation Help at the upper right corner of the Visit interface to refer to the troubleshooting. 3. Start the application and register for a Hik-Connect user account. 4. Log in after registration.
  • Page 69 Visit to download the application according to your mobile phone system. Visit the official site of our company, then go to Support → Tools → Hikvision App Store. Scan the QR code below to download the application. NOTE: If errors (e.g., “Unknown app”) occur during installation, refer to the following: https://appstore.hikvision.com/static/help/index.html...
  • Page 70 Network Camera User Manual 5. Input the verification code of your camera. NOTE: The required verification code is the code you create or change when you enable Hik-Connect service on the camera. If you forget the verification code, you can check the current verification code on the Platform Access configuration page via a Web browser.

  • Page 71: Chapter 8 Arming Schedule And Alarm Linkage

    Network Camera User Manual Chapter 8 Arming Schedule and Alarm Linkage Arming schedule is a customized time period during which the device performs certain tasks. Alarm linkage is the response to the detected incident or target during the scheduled time. 8.1 Set Arming Schedule Set the valid time of the device tasks.

  • Page 72: Ftp/Nas/Memory Card Uploading

    Network Camera User Manual Manual Alarm You can trigger an alarm output manually. Steps 1. Set the manual alarm parameters. • Alarm Output No.: Select the alarm output no. according to the alarm interface connected to the external alarm device. •...

  • Page 73: Notify Surveillance Center

    Network Camera User Manual when an alarm event is detected. Set Email NOTE: For e-mail settings, refer to Set Email When the e-mail is configured and Send Email is enabled as a linkage method, the device sends an e-mail notification to all designated receivers if an alarm event is detected. Before You Start Set the DNS server before using the Email function.

  • Page 74: Flashing Light

    Network Camera User Manual Video Recording and Picture Capture. settings, refer to 8.2.6 Flashing Light After enabling Flashing Light and setting the Flashing Light Alarm Output, the light flashes when an alarm event is detected. Set Flashing Alarm Light Output When events occur, the flashing light on the device can be triggered as an alarm.
  • Page 75 Network Camera User Manual files can be uploaded. 3. Optional: Click Test to play the selected audio file on the device. Set Arming Schedule 4. Set arming schedule for audible alarm. See for details. 5. Click Save. NOTE: The function is supported only by certain device models. UM Network Camera User Manual 071421NA...

  • Page 76: Chapter 9 System And Security

    Network Camera User Manual Chapter 9 System and Security It introduces system maintenance, system settings and security management, and explains how to configure relevant parameters. 9.1 View Device Information You can view device information such as Device No., Model, Serial No., and Firmware Version. Enter Configuration →...

  • Page 77: Restore And Default

    Network Camera User Manual Go to Configuration → System → Maintenance → Upgrade & Maintenance, and click Reboot. 9.7 Restore and Default Restores the device parameters to the default settings. Steps 1. Go to Configuration → System → Maintenance → Upgrade & Maintenance. 2.

  • Page 78: Synchronize Time Manually

    Network Camera User Manual 9.10.1 Synchronize Time Manually Steps 1. Go to Configuration → System → System Settings → Time Settings. 2. Select Time Zone. 3. Click Manual Time Sync. 4. Choose one time synchronization method. • Select Set Time, and manually input or select date and time from the pop-up calendar. •...

  • Page 79: Set Dst

    Network Camera User Manual 4. Click Save. 9.10.4 Set DST If the region where the device is located adopts Daylight Saving Time (DST), you can set this function. Steps 1. Go to Configuration → System → System Settings → DST. 2.

  • Page 80: External Device

    Network Camera User Manual 9.13 External Device For devices supporting external devices, including the supplement light, wiper on the housing, and the LED light, you can control them via the Web browser when it is used with the housing. External devices vary with models.

  • Page 81: Set Ip Address Filter

    Network Camera User Manual RTSP Digest Algorithm: MD5, SHA256, and MD5/SHA256 encrypted algorithm in RTSP authentication. If • you enable the digest algorithm except for MD5, the third-party platform might not be able to log in to the device or enable live view because of compatibility. The encrypted algorithm with high strength is recommended.

  • Page 82: Set Qos

    Network Camera User Manual 1. Go to Configuration → Network → Advanced Settings → HTTPS. 2. Check Enable to access the camera via HTTP or HTTPS protocol. 3. Check Enable HTTPS Browsing to access the camera only via HTTPS protocol. 4.

  • Page 83: Search Security Audit Logs

    Network Camera User Manual If this function is enabled, you will be logged out when you make no operation (not including viewing live image) to the device via Web browser within the set timeout period. Go to Configuration → System → Security → Advanced Security to complete settings. 9.14.7 Search Security Audit Logs You can search and analyze the security log files of the device so as to find out the illegal intrusion and troubleshoot the security events.

  • Page 84: Create Certificate Request

    Network Camera User Manual 9.15.2 Create Certificate Request Before You Start Select a self-signed certificate. Steps 1. Click Create Certificate Request. 2. Enter the related information. 3. Click OK. 9.15.3 Import Certificate Steps 1. Click Import. 2. Click Create Certificate Request. 3.

  • Page 85: Install Ca Certificate

    Network Camera User Manual • Create certificate request: Refer to Create Certificate Request • Import Certificate Import Certificate: Refer to 9.15.5 Install CA Certificate Steps 1. Click Import. 2. Enter the Certificate ID. 3. Click Browser to select the desired server/client certificate. 4.

  • Page 86: Simultaneous Login

    Network Camera User Manual Steps 1. Go to Configuration → System → User Management → User Management. 2. Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to users based on needs. • Administrator: The administrator has the authority to all operations and can add users and operators and assign permissions.

  • Page 87: Chapter 10 Allocate Vca Resource

    Network Camera User Manual Chapter 10 Allocate VCA Resource VCA resource offers you options to enable certain VCA functions according to actual needs. It helps allocate more resources to the desired functions. Steps 1. Go to Configuration → System → System Settings → VCA Resource. 2.

  • Page 88: Overlay And Capture

    Network Camera User Manual Figure 11, Set Face Capture NOTE: The device will detect whether there is a human face in the area by the set minimum pupil distance. Set Arming Schedule 6. For arming schedule settings, refer to . For linkage method settings, refer to Linkage Method Settings 7.

  • Page 89: Face Capture Algorithms Parameters

    Network Camera User Manual Text Overlay: You can check desired items and adjust their order to display on captured pictures by • . The content of Device No. and Camera Info should be on the same page. using 10.1.3 Face Capture Algorithms Parameters Set and optimize the parameters of the algorithm library for face capture.

  • Page 90: Set Shield Region

    Network Camera User Manual detected face when the face stays in the scene for 5 seconds. NOTE: The face filtering time (longer than 0s) may increase the possibility of the actual capture times less than the set value above. ­ Restore Default: Click Restore to restore all the advanced configuration settings to the factory defaults.

  • Page 91: Set Mixed-Traffic Detection Rule

    Network Camera User Manual NOTE: Only one license plate can be captured at one time for each lane. 7. Select Region and Country/Region. 8. Select the license plate information upload mode. • Entrance/Exit: The license plate information of the detected vehicle will be uploaded when the vehicle passes the detection area and triggers the detection in entrance/exit.

  • Page 92: Uploading Pictures Settings

    Network Camera User Manual 6. Click Save. 10.2.3 Uploading Pictures Settings You can set the image parameters of the captured images in vehicle detection and mixed-traffic detection. Go to Configuration → Road Traffic → Picture. Picture Quality: The larger the value, the clearer the picture, but more storage space is also required. •...

  • Page 93: Multi-Target-Type Detection

    Network Camera User Manual 10.3 Multi-Target-Type Detection Multi-Target-Type Detection is to detect, capture, and upload data of targets in multiple types such as human faces, human bodies, and vehicles. NOTE: For certain device models, you need to enable Multi-Target-Type Detection on the VCA Resource page first.

  • Page 94: Multi-Target-Type Detection Algorithm Parameters

    Network Camera User Manual Background Picture Settings: Compared to the target picture, the background picture is the scene • image that offers extra environmental information. You can set the background picture quality and resolution. If the background image needs to be uploaded to the surveillance center, check Background Upload.

  • Page 95: Set Shield Region

    Network Camera User Manual ­ Face Filtering Time: The time interval between the camera detecting a face and taking a capture action. If the detected face stays in the scene for less than the set filtering time, capture will not be triggered.

  • Page 96: Overlay And Capture

    Network Camera User Manual window, and right-clicking to finish the area drawing. 3) Click to draw the detection line. The arrow shows entering direction, you can click change the direction. • If the target crosses the counting area from the entering direction and crosses the detection line, then it is counted as the entering number.

  • Page 97: View Face Counting Result

    Network Camera User Manual NOTE: These functions vary by models. • Face Capture Mode: The current algorithm version, which cannot be edited. • Best Shot: The best shot after the target leaves the detection area. Capture Times: The capture times a face will be captured during its stay in the configured area. The •...

  • Page 98: Set Waiting Time Detection

    Network Camera User Manual Before You Start To enable the function, go to VCA Resource, and select Queue Management. Steps 1. Go to Configuration → Queue Management. 2. Select Regional People Queuing-Up. 3. Click Add Region to draw the detection area and set Region Name and Alarm Interval. Repeat this step above to set more areas.

  • Page 99: Queue Management Statistics

    Network Camera User Manual 3. Click Add Region to draw the detection area and set Region Name and Alarm Interval. Repeat this step above to set more areas. • Alarm Interval: During the set alarm interval, alarms of the same type trigger only one notification. Figure 13, Set Waiting Time Detection 4.

  • Page 100: Counting

    Network Camera User Manual Steps NOTE: With an on-board memory card installed, the device can save up to one mouth’s data. With no memory card installed, the device can save only up to one week’s data. 1. Select the analysis mode. •...

  • Page 101: View Counting Statistics

    Network Camera User Manual • Draw a detection line. • Delete the detection line. • Change the direction. Figure 14, Set Counting Set Arming Schedule 5. For arming schedule settings, refer to . For linkage method settings, refer to Linkage Method Settings 6.

  • Page 102: Set Hard Hat Detection

    Network Camera User Manual NOTE: Only certain device models support the function. 10.7.1 Set Hard Hat Detection Before You Start Go to Configuration → System → System Settings → VCA Resources to enable Hard Hat Detection. Steps 1. Go to Configuration → Hard Hat Detection, and check Enable Hard Hat Detection. 2.
  • Page 103 Network Camera User Manual 1) Click to add a face picture library. 2) Input library name, threshold and remarks. • Threshold: Face similarity higher than the set threshold triggers face picture comparison alarm uploading. 3) Click OK. 4) Optional: Modify a face picture library. Select the desired library and click and change related parameters.
  • Page 104 Network Camera User Manual 7. Click Save. Set Face Picture Comparison Compares captured pictures with face pictures in a library and outputs comparison result. Comparison result can trigger certain actions when arming schedule and linkage method are set. Before You Start Set Face Picture Library You should first create a face picture library and add face pictures.

  • Page 105: Face Modeling

    Network Camera User Manual 2. Set search condition and click Counting. Matched results are shown in Face Picture Comparison Statistics area. 10.8.2 Face Modeling Collects face pictures, creates face models, and uploads data to the surveillance center. Before You Start Face Capture Configure Face Capture or Multi-Target-Type detection for face picture collection.

  • Page 106: Chapter 11 Open Platform

    Network Camera User Manual Chapter 11 Open Platform Open platform allows you to install the application for a third-party to develop and run its function and service. NOTE: Only certain device models support this function. 11.1 Set Open Platform Steps 1.
  • Page 107 Network Camera User Manual • Delete the application. • Enable or disable the application. 5. Optional: In application display, click Browse and import the application certificate. UM Network Camera User Manual 071421NA...

  • Page 108: Chapter 12 Set Eptz

    Network Camera User Manual Chapter 12 Set EPTZ EPTZ (Electronic PTZ) is a high-resolution function that digitally zooms and pans into portions of the image, with no physical camera movement. Before You Start To use the EPTZ function, select Fourth Stream in live view. Fourth stream and EPTZ must be both enabled simultaneously.

  • Page 109: Chapter 13 Smart Display

    Network Camera User Manual Chapter 13 Smart Display Displays captured pictures when enabling smart functions. • Layout Preview: Click and select Layout Preview. Select the contents according to your needs. When you select real-time analysis, you can select the contents only for real-time analysis. •...

  • Page 110: Device Commands

    Network Camera User Manual Device Commands Scan the following QR code to get device common serial port commands. Note that the command list contains the commonly used serial port commands for all Hikvision network cameras. UM Network Camera User Manual 071421NA...

  • Page 111: Device Communication Matrix

    Network Camera User Manual Device Communication Matrix Scan the following QR code to get device communication matrix. Note that the matrix contains all communication ports of Hikvision network cameras. UM Network Camera User Manual 071421NA...

Table of Contents
