  • Page 1 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual...

  • Page 2: Symbol Conventions

    BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS. YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY RISKS, AND...

  • Page 3: Safety Instruction

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Symbol Description Indicates a hazardous situation which, if not avoided, will or could result in death or Danger serious injury. Indicates a potentially hazardous situation which, if not avoided, could result in Caution equipment damage, data loss, performance degradation, or unexpected results. Provides additional information to emphasize or supplement important points of the main text.
  • Page 4 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Environment • Make sure the running environment meets the requirement of the device. The operating temperature shall be -30° to 60° C (-22° to 140° F), and the operating humidity shall be 95% or less, non-condensing. •...

  • Page 5: Table Of Contents

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Contents Symbol Conventions............................2 Safety Instruction ............................. 3 Contents ................................5 Chapter 1 System Requirements ........................10 Chapter 2 Device Activation and Accessing ....................11 Activate the Device via SADP ........................11 Activate the Device via Browser ........................ 11 Login ................................
  • Page 6 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Audio Output ..........................25 Environmental Noise Filter ......................25 Two-Way Audio ............................25 Display Settings ............................26 Scene Mode ............................ 26 Image Parameters Switch ......................28 Video Standard ..........................28 Local Video Output ........................28 OSD ................................
  • Page 7 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Draw Area ............................52 Set Size Filter ..........................52 Chapter 7 Network Settings ..........................53 TCP/IP................................53 Multicast ............................53 Multicast Discovery ........................54 SNMP ................................54 Set SRTP ............................... 54 Port Mapping..............................55 Set Auto Port Mapping ........................
  • Page 8 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Synchronize Time Manually ......................75 Set NTP Server ..........................75 Synchronize Time by Satellite ....................... 75 Set DST ............................76 Set RS-485 ..............................76 Set RS-232 ..............................76 External Device ............................77 Supplement Light Settings ......................77 Security ................................
  • Page 9 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual View Face Counting Result ......................94 Queue Management ............................ 94 Set Regional People Queuing-Up ....................95 Set Waiting Time Detection ......................95 Queue Management Statistics ..................... 96 Counting ..............................97 Set Counting ..........................97 View Counting Statistics .......................

  • Page 10: Chapter 1 System Requirements

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 1 System Requirements Your computer should meet the requirements for proper visiting and operating the product. • Operating System: Microsoft Windows XP SP1 and above version • CPU: 2.0 GHz or higher • RAM: 1 GB or more •...

  • Page 11: Chapter 2 Device Activation And Accessing

    Activate the Device via SADP Search and activate the online devices via SADP software. Before You Start Access www.hikvision.com to get SADP software to install. Steps 1. Connect the device to network using the network cable. 2. Run SADP software to search the online devices.

  • Page 12: Login

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 3. Input 192.168.1.64 in the browser. 4. Set device activation password. STRONG PASSWORD RECOMMENDED − We highly recommend that you create a strong password of your own choosing (using a minimum of eight characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.

  • Page 13: Admin Password Recovery

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Admin Password Recovery If you forget the admin password, you can reset the password by clicking Forget Password on the login page after completing the account security settings. You can reset the password by setting the security question or e-mail. When you need to reset the password, make sure that the device and the PC are on the same network segment.

  • Page 14: Chapter 3 Live View

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 3 Live View Introduction to live view parameters, function icons, and transmission parameters settings. Live View Parameters The supported functions vary by model. Enable and Disable Live View This function is used to quickly enable or disable live view of all channels. •...

  • Page 15: Window Division

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Window Division • : 1 × 1 window division • : 2 × 2 window division • : 3 × 3 window division • : 4 × 4 window division Light Click to turn on or turn off the illuminator. Count Pixel Use to get the height and width pixel of the selected region in the live view image.

  • Page 16: Quick Set Live View

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Lens initialization is used on devices equipped with a motorized lens. The function can reset the lens when long time zoom or focus results in blurred image. This function varies by model. • Manual Lens Initialization: Click to operate lens initialization.

  • Page 17: Conduct 3D Positioning

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual ­ When the image is too dark, click to enlarge the iris. ­ When the image is too bright, click to stop down the iris. Conduct 3D Positioning 3D positioning relocates the selected area to the image center. Steps 1.

  • Page 18: Set Smooth Streaming

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual HTTP is suitable for situations in which a third-party needs to get the stream from the device. • Play Performance ­ Shortest Delay The device takes the real-time video image as the priority over the video fluency. ­...
  • Page 19 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • Error Correction: The resolution and bitrate stay the same as the set values on Video page. The mode is used to correct the data error during transmission to ensure the image quality. You can set the Error Correction Proportion within range of 0–100.

  • Page 20: Chapter 4 Video And Audio

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 4 Video and Audio This part introduces the configuration of video and audio related parameters. Video Settings This section introduces video parameter settings such as stream type, video encoding, and resolution. 1. Go to setting page: Configuration → Video/Audio → Video. Stream Type For devices that support more than one stream, you can specify parameters for each stream type.

  • Page 21: Resolution

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • Video: Only video content is contained in the stream. • Video & Audio: Video content and audio content are contained in the composite stream. Resolution Select video resolution according to actual needs. Higher resolution requires more bandwidth and storage. Bitrate Type and Max.

  • Page 22: Smoothing

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • H.265+: H.265+ is an improved compression coding technology based on H.265. By enabling H.265+, you can estimate the HDD consumption by its maximum average bitrate. Compared to H.265, H.265+ reduces storage by up to 50% with the same maximum bitrate in most scenes. When H.265+ is enabled, Max.

  • Page 23: Set Roi

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Set ROI ROI (Region of Interest) encoding helps to assigns more encoding resource to the region of interest, thus to increase the quality of the ROI whereas the background information is less focused. Before You Start Please check the video coding type.

  • Page 24: Set Target Tracking Roi

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Set Target Tracking ROI The moving target is clearer than other areas in live image or recordings after enabling the function. Before You Start Go to Configuration → PTZ → Smart Tracking to complete the smart tracking settings. Steps 1.

  • Page 25: Audio Settings

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Audio Settings This function sets audio parameters such as audio encoding and environment noise filtering. Go to the audio settings page: Configuration → Video/Audio → Audio. Audio Encoding Select the audio encoding compression of the audio. Audio Input Connect the audio input device as required.

  • Page 26: Display Settings

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 4. Click , disable the two-way audio function. Display Settings This offers the parameter settings to adjust image features. Go to Configuration → Image → Display Settings. Click Default to restore settings. Scene Mode There are several sets of image parameters predefined for different installation environments.
  • Page 27 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • Day/Night Switch Day/Night Switch function can provide color images in te day mode and black/white images in night mode. Switch mode is configurable. ­ Day: The image is always in color. ­ Night: The image is always black/white. ­...

  • Page 28: Image Parameters Switch

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • DNR: Digital Noise Reduction is used to reduce the image noise and improve the image quality. Normal and Expert modes are selectable. ­ Normal: Set the DNR level to control the noise reduction. Use a higher level for more reduction. ­...

  • Page 29: Osd

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual You can customize OSD (On-screen Display) information such as device name, time/date, font, color, and text overlay displayed on video stream. Go to OSD setting page: Configuration → Image → OSD Settings. Set the corresponding parameters, and click Save to take effect.

  • Page 30: Set Target Cropping

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Steps 1. Go to picture overlay setting page: Configuration → Image → Picture Overlay. 2. Click Browse to select a picture, and click Upload. The picture with a red rectangle will appear in live view after successfully uploading. 3.

  • Page 31: Chapter 5 Video Recording And Picture Capture

    4. Click Save. Detect Memory Card Status Detects the memory card status of Hikvision memory card. You receive notifications when your memory card is detected to be abnormal. Before You Start Memory card should be installed to the device.

  • Page 32: Set Ftp

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 3. Click R/W Lock to set the reading and writing authority of the memory card. 1) Add a LockSelect the Lock Switch as ON. 2) Enter the password. 3) Click Save. Unlock • If you use the memory card on the camera that locks it, unlocking will be done automatically and no unlocking procedures are required on the part of users.

  • Page 33: Set Nas

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • User Name and Password: The FTP user should have the permission to upload pictures. If the FTP server supports picture uploading by anonymous users, you can check Anonymous to hide your device information during uploading. •...

  • Page 34: Emmc Protection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 2. Click Save. eMMC Protection If you enable eMMC protection, the lifespan of the eMMC is displayed. Set Cloud Storage It helps to upload the captured pictures and data to the cloud. The platform requests picture directly from the cloud for picture and analysis.

  • Page 35: Record Manually

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Steps 1. Go to Configuration → Storage → Schedule Settings → Record Schedule. 2. Check Enable. 3. Select a record type. The record types vary by model. • Continuous: The video will be recorded continuously according to the schedule. •...

  • Page 36: Set Lite Storage

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 2. Set the Record File Size and saving path to for recorded files. 3. Click Save. 4. Click to start recording. Click to stop recording. Set Lite Storage After lite storage is enabled, the video stream frame rate and bitrate can be reduced to lengthen the storage time of the memory card when there is no moving object in the monitoring scenario.

  • Page 37: Capture Configuration

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 2) Select the video files and then click Download. Go to Configuration → Local, click Save downloaded files to to change the saving path of downloaded video files. Capture Configuration The device can capture the pictures manually or automatically and save them in configured saving path. You can view and download the snapshots.

  • Page 38: View And Download Pictures

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual View and Download Pictures You can search, view, and download the pictures stored in the local storage or network storage. Steps 1. Click Picture. 2. Set search condition and click Search. Matching pictures show in the file list. 3.

  • Page 39: Chapter 6 Events And Alarms

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 6 Events and Alarms This section introduces configuring events. The device takes certain responses to triggered alarms. Basic Event Set Motion Detection Motion detection detects moving objects in the detection region and triggers linked actions. Steps 1.
  • Page 40 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual It switches to day mode during the set periods and switches to night mode during the other periods. • Sensitivity: The higher the sensitivity value, the more sensitive the motion detection. If the sensitivity is set to 0, motion detection and dynamic analysis do not take effect. •...

  • Page 41: Set Video Tampering Alarm

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Figure 6-2 Set Rules 4. Optional: You can set the parameters of multiple areas by repeating the above steps. Set Video Tampering Alarm When the configured area is covered and cannot be monitored normally, the alarm is triggered and the device takes certain alarm response actions.

  • Page 42: Set Pir Alarm

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Figure 6-3 Set Video Tampering Area 5. Refer to Set Arming Schedule for setting scheduled time. Refer to Linkage Method Settings for setting linkage method. 6. Click Save. Set PIR Alarm A PIR (Passive Infrared) alarm is triggered when an intruder moves within the detector’s field of view. The heat energy dissipated by a person or any other warm blooded creature such as a dog, cat, etc.

  • Page 43: Set Alarm Input

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 1. Go to Configuration → Event → Basic Event → Exception. 2. Select Exception Type. • HDD Full: The HDD storage is full. • HDD Error: Error occurred in HDD. • Network Disconnected: The device is offline. •...

  • Page 44: Set Vibration Detection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Steps 1. Go to Configuration → Event → Basic Event → Video Quality Diagnosis. 2. Select Diagnosis Type. 3. Set the corresponding parameters. • Alarm Detection Interval: The time interval to detect the exception. •...

  • Page 45: Detect Audio Exception

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Detect Audio Exception Audio exception detection function detects the abnormal sound in the surveillance scene such as the sudden increase/decrease of the sound intensity, and certain actions can be taken in response. Steps 1. Go to Configuration → Event → Smart Event → Audio Exception Detection. 2.

  • Page 46: Detect Scene Change

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Detect Scene Change This detects change of the surveillance scene. Certain actions can be taken when the alarm is triggered. Steps 1. Go to Configuration → Event → Smart Event → Scene Change Detection. 2.

  • Page 47: Set Intrusion Detection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 3. See Set Arming Schedule for setting scheduled time. See Linkage Method Settings for setting linkage method. 4. Click Save. Set Intrusion Detection Detects objects entering and loitering in a pre-defined virtual region, after which the device can take linkage actions.

  • Page 48: Set Line Crossing Detection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Set Line Crossing Detection Detects objects crossing a pre-defined virtual line. If it occurs, the device can take linkage actions. Steps 1. Go to Configuration → Event → Smart Event → Line Crossing Detection. 2.

  • Page 49: Set Region Entrance Detection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 8. Click Save. Set Region Entrance Detection Use to detect objects entering a pre-defined virtual region. If it occurs, the device can take linkage actions. Steps 1. Go to Configuration → Event → Smart Event → Region Entrance Detection. 2.

  • Page 50: Set Unattended Baggage Detection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 4. Select the detection target. Human and Vehicle are available. If the detection target is not selected, all detected targets will be reported, including humans and vehicles. Figure 6-7 Set Rule 5. Optional: You can set the parameters of multiple areas by repeating the above steps. 6.

  • Page 51: Set Object Removal Detection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Figure 6-8 Set Rule 5. Optional: You can set the parameters of multiple areas by repeating the above steps. 6. For the arming schedule settings, refer to Set Arming Schedule. For the linkage method settings, refer to Linkage Method Settings.

  • Page 52: Draw Area

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Figure 6-9 Set Rule 5. Optional: Repeat the above steps to set more regions. 6. For the arming schedule settings, see Set Arming Schedule. For the linkage method settings, see Linkage Method Settings. 7. Click Save. The function is supported only by certain models.

  • Page 53: Chapter 7 Network Settings

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 7 Network Settings TCP/IP TCP/IP settings must be properly configured before you operate the device over a network. IPv4 and IPv6 are both supported. Both versions can be configured simultaneously without conflicting with each other. 1.

  • Page 54: Multicast Discovery

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • IP Address: Address of multicast host • Stream Type: Stream type of the multicast source • Video Port: Video port of the selected stream • Audio Port: Audio port of the selected stream •...

  • Page 55: Port Mapping

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 2. Select Server Certificate. 3. Select Encrypted Algorithm. 4. Click Save. Only certain device models support this function. If the function is abnormal, check if the selected certificate is abnormal in certificate management. Port Mapping By setting port mapping, you can access devices through the specified port.

  • Page 56: Set Port Mapping On Router

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual What To Do Next Go to the router port mapping settings interface and set the port number and IP address to be the same as those on the device. For more information, see the router user manual. Set Port Mapping on Router The following settings are for a specific router.

  • Page 57: Access To Device Via Domain Name

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • HTTP Port: Port through which the browser accesses the device. For example, when the HTTP Port is modified to 81, you need to enter http://192.168.1.64:81 in the browser for login. • HTTPS Port: Port through which the browser accesses the device with certificate. Certificate verification is required to ensure secure access.

  • Page 58: Access To Device Via Pppoe Dial Up Connection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • By Browser: Enter the domain name in the browser address bar to access the device. • By Client Software: Add domain name to the client software. Refer to the client manual for specific adding methods.

  • Page 59: Set Wireless Dial

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Set Wireless Dial The built-in wireless module offers dial-up access to the Internet for the device. Before You Start Get a SIM card, and activate 3G/4G services. Insert the SIM card into the corresponding slot. Steps 1.

  • Page 60: Wi-Fi

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 4) Click Save. 5) Optional: Repeat the steps above to set multiple recipients. • : Modify the white list parameters. • : Delete the white list that already set. • Send Test SMS: Send a message to the mobile phone for test. 4.
  • Page 61 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Use PBC Set PBC to connect Wi-Fi automatically. PBC refers to Push-Button-Configuration, in which the user simply has to push a button, either an actual or virtual one (as the Connect button on the configuration interface of the IE browser), on both the Access Point (and a registrar of the network) and the new wireless client device.
  • Page 62 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Use PIN on Device The device can automatically connect the network by setting the device PIN code parameters in wireless router or AP via WPS or QSS protocols. Steps 1. Go to TCP/IP settings page: Configuration → Network → Basic Configuration → TCP/IP. 2.

  • Page 63: Set Network Service

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 4) Click Connect. 5. Click Save. 6. Go to TCP/IP setting page: Configuration → Network → Basic Configuration → TCP/IP, and click Wlan to check the IPv4 Address and log in the device. • Input the IP address in the browser to access the device. •...

  • Page 64: Set Alarm Server

    1. Get and install Hik-Connect application by the following ways. • Visit https://appstore.hikvision.com to download the application according to your mobile phone system. • Visit the official site of our company. Then go to Support → Tools → Hikvision App Store. UM iDS-2CD7xxG0-xxxxx 021021NA...

  • Page 65: Enable Hik-Connect Service On Camera

    If errors such as “Unknown app” occur during the installation, solve the problem in two ways. Visit https://appstore.hikvision.com/static/help/index.html to refer to the troubleshooting. Visit https://appstore.hikvision.com/, and click Installation Help at the upper right corner of the interface to refer to the troubleshooting.

  • Page 66: Set Up Hik-Connect

    • Visit https://appstore.hikvision.com to download the application according to your mobile phone system. • Visit the official site of our company. Then go to Support → Tools → Hikvision App Store. • Scan the QR code below to download the application.

  • Page 67: Add Camera To Hik-Connect

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 2. Start the application and register for a Hik-Connect user account. 3. Log in after registration. Add Camera to Hik-Connect Steps 1. Connect your mobile device to a Wi-Fi. 2. Log into the Hik-Connect app. 3.

  • Page 68: Chapter 8 Arming Schedule And Alarm Linkage

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 8 Arming Schedule and Alarm Linkage Arming schedule is a customized time period in which the device performs certain tasks. Alarm linkage is the response to the detected certain incident or target during the scheduled time. Set Arming Schedule Set the valid time of the device tasks.

  • Page 69: Ftp/Nas/Memory Card Uploading

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Steps 1. Set the manual alarm parameters. • Alarm Output No.: Select the alarm output no. according to the alarm interface connected to the external alarm device. • Alarm Name: Custom a name for the alarm output. •...

  • Page 70: Notify Surveillance Center

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Set E-mail When the e-mail is configured and Send Email is enabled as a linkage method, the device sends an e-mail notification to all designated receivers if an alarm event is detected. Before You Start Set the DNS server before using the E-mail function.

  • Page 71: Flashing Light

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Flashing Light After enabling Flashing Light and setting the Flashing Light Alarm Output, the light flashes when an alarm event is detected. Set Flashing Alarm Light Output When events occur, the flashing light on the device can be triggered as an alarm. Steps 1.
  • Page 72 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 3. Optional: Click Test to play the selected audio file on the device. 4. Set arming schedule for audible alarm. See Set Arming Schedule for details. 5. Click Save. The function is supported only by certain device models. UM iDS-2CD7xxG0-xxxxx 021021NA...

  • Page 73: Chapter 9 System And Security

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 9 System and Security This section is an introduction to system maintenance, system settings, and security management, and explains how to configure relevant parameters. View Device Information You can view device information, such as Device No., Model, Serial No., and Firmware Version. Enter Configuration →...

  • Page 74: Restore And Default

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Restore and Default Restore and Default helps restore the device parameters to the default settings. Steps 1. Go to Configuration → System → Maintenance → Upgrade & Maintenance. 2. Click Restore or Default according to your needs. •...

  • Page 75: Synchronize Time Manually

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Synchronize Time Manually Steps 1. Go to Configuration → System → System Settings → Time Settings. 2. Select Time Zone. 3. Click Manual Time Sync.. 4. Choose one time synchronization method. • Select Set Time, and manually input or select date and time from the pop-up calendar. •...

  • Page 76: Set Dst

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 4. Click Save. Set DST If the region where the device is located adopts Daylight Saving Time (DST), you can set this function. Steps 1. Go to Configuration → System → System Settings → DST. 2.

  • Page 77: External Device

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual External Device For devices that support external devices, including the supplement light, wiper on the housing, and the LED light, you can control them via the Web browser when it is used with the housing. External devices vary by model.

  • Page 78: Set Ip Address Filter

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual the device or enable live view because of compatibility. An encrypted algorithm with high strength is recommended. • WEB Authentication: Digest and digest/basic are supported, which means authentication information is needed when a Web request is sent to the device. If you select digest/basic, it means the device supports digest or basic authentication.

  • Page 79: Set Qos

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 2. Check Enable to access the camera via HTTP or HTTPS protocol. 3. Check Enable HTTPS Browsing to access the camera only via HTTPS protocol. 4. Select the Server Certificate. 5. Click Save. If the function is abnormal, check if the selected certificate is abnormal in Certificate Management.

  • Page 80: Search Security Audit Logs

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 1. Go to Configuration → System → Security → Advanced Security to complete settings. Search Security Audit Logs You can search and analyze the security log files of the device so as to find out illegal intrusions and troubleshoot security events.

  • Page 81: Create Certificate Request

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Create Certificate Request Before You Start Select a self-signed certificate. Steps 1. Click Create Certificate Request. 2. Enter the related information. 3. Click OK. Import Certificate Steps 1. Click Import. 2. Click Create Certificate Request. 3.

  • Page 82: Install Ca Certificate

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • Create Certificate Request: Refer to Create Certificate Request • Import Certificate: Refer to Import Certificate Install CA Certificate Steps 1. Click Import. 2. Enter the Certificate ID. 3. Click Browser to select the desired server/client certificate. 4.

  • Page 83: Simultaneous Login

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Steps 1. Go to Configuration → System → User Management → User Management. 2. Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to users based on needs. • Administrator: The administrator has the authority for all operations and can add users and operators and assign permission.

  • Page 84: Chapter 10 Allocate Vca Resource

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 10 Allocate VCA Resource VCA resource offers options to enable certain VCA functions according to actual needs. It helps allocate more resources to the desired functions. Steps 1. Go to Configuration → System → System Settings → VCA Resource. 2.

  • Page 85: Overlay And Capture

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Figure 10-1 Set Face Capture The device will detect if there is a human face in the area by the set minimum pupil distance. 6. For the arming schedule settings, refer to Set Arming Schedule. For the linkage method settings, refer to Linkage Method Settings.

  • Page 86: Face Capture Algorithms Parameters

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • Text Overlay: You can check desired items and adjust their order to display on captured pictures by . The content of Device No. and Camera Info should be on the same page. Face Capture Algorithms Parameters Use to set and optimize the parameters of the algorithm library for face capture.

  • Page 87: Set Shield Region

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual ­ Face Filtering Time: Time interval between the camera detecting a face and taking a capture action. If the detected face stays in the scene for less than the set filtering time, capture will not be triggered.

  • Page 88: Set Mixed-Traffic Detection Rule

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 5. Click and drag the lane line to set its position, or click and drag the line end to adjust the length and angle of the line. 6. Adjust the zoom ratio of the camera so that the size of the vehicle in the image is close to that of the red frame.

  • Page 89: Uploading Pictures Settings

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 2. Select Mixed-Traffic Detection as detection type. 3. Check Enable. 4. Select the lane number. 5. Select Region and Country/Region. 6. Set arming schedule and linkage method. For the arming schedule settings, refer to Set Arming Schedule.

  • Page 90: Multi-Target-Type Detection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 4. Click Export to open the PC local directory. 5. Select a directory in your PC local directory. 6. Name the file in the file name text filed. 7. Click Save. Multi-Target-Type Detection Multi-Target-Type Detection is to detect, capture, and upload data of targets of multiple types such as human face, human body, and vehicle.

  • Page 91: Multi-Target-Type Detection Algorithm Parameters

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • Display Target info. on Alarm Picture: Overlay the alarm picture with target information. • Target Picture Settings: Custom, Head Shot, Half-Body Shot, and Full-Body Shot are selectable. If you select Custom, you can customize width, head height, and body height as required. You can check Fixed Value to set the picture height.

  • Page 92: Set Shield Region

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual level. If a face in the actual scene is darker than the set reference, the device increases the exposure level. ­ Minimum Duration: The extra time the device keeps the face exposure level after the face disappears in the scene.

  • Page 93: Overlay And Capture

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • Max. Pupil Distance: The max. pupil distance refers to the maximum square size composed by the area between two pupils, and it is the basic standard for a camera to identify a target. 5.

  • Page 94: Face Counting Algorithm Parameters

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Face Counting Algorithm Parameters It is used to set and optimize the parameters of the algorithm parameters for Face Counting. These functions vary according to different models. • Face Capture Mode: Current algorithm version, which cannot be edited. •...

  • Page 95: Set Regional People Queuing-Up

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Set Regional People Queuing-Up Use to count queuing-up persons in defined regions. Alarms are triggered when the alarm threshold condition and the alarm trigger are both met. Before You Start To enable the function, go to VCA Resource, and select Queue Management. Steps 1.

  • Page 96: Queue Management Statistics

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Steps 1. Go to Configuration → Queue Management. 2. Select Waiting Time Detection. 3. Click Add Region to draw the detection area and set Region Name, and Alarm Interval. Repeat this step above to set more areas. •...

  • Page 97: Counting

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual • Select Queue Status Analysis and Multi-Level Comparison to compare the time and duration of the queue at different queue length levels. Steps With an on-board memory card installed, the device can save up to one month’s data. With no memory card installed, the device can save only up to one week’s data.

  • Page 98: View Counting Statistics

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 4. Set the detection line and the objects across the line will be detected and counted. • : Draw a detection line. • : Delete the detection line. • : Change the direction. Figure 10-4 Set Counting 5.

  • Page 99: Set Hard Hat Detection

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Only certain device models support the function. Set Hard Hat Detection Before You Start 1. Go to Configuration → System → System Settings → VCA Resources to enable Hard Hat Detection. Steps 1. Go to Configuration → Hard Hat Detection, and check Enable Hard Hat Detection. 2.
  • Page 100 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual 2) Input library name, threshold and remarks. • Threshold: Face similarity higher than set threshold triggers face picture comparison alarm uploading. 3) Click OK. 4) Optional: Modify face picture library. Select library, click , and change related parameters. 5) Optional: Delete a library.
  • Page 101 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Set Face Picture Comparison The function compares captured pictures with face pictures in library and outputs comparison result. Comparison result can trigger certain actions when arming schedule and linkage method are set. Before You Start You should first create a face picture library and add face pictures.

  • Page 102: Face Modeling

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Face Modeling Face modeling serves the purpose of collecting face pictures, creating face models, and uploading data to the surveillance center. Before You Start Face Capture or Multi-Target-Type detection should be configured for face picture collection. See Face Capture or Multi-Target-Type Detection for configuration instructions.

  • Page 103: Chapter 11 Open Platform

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 11 Open Platform Open platform allows you to install a third-party application to develop and run its functions and services. Only certain device models support this function. Set Open Platform 1. Go to Configuration → Open Platform. Before installing the application, read the Disclaimer at the bottom and make sure that the application you want to install fits the following conditions.

  • Page 104: Chapter 12 Set Eptz

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 12 Set EPTZ EPTZ (Electronic PTZ) is a high-resolution function that digitally zooms and pans into portions of the image, with no physical camera movement. Before You Start If you want to use the EPTZ function, make sure you have select the Fourth Stream in the live view. Fourth stream and EPTZ must both be enabled simultaneously.

  • Page 105: Chapter 13 Smart Display

    iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual Chapter 13 Smart Display Displays captured pictures when enabling smart functions. Layout Preview Click and select Layout Preview. Select the contents according to your needs. When you select real-time analysis, you can select the contents only for real-time analysis. Detection Attribute Click and select Detection Attribute.

  • Page 106: Appendix A: Device Command

    Network Bullet Camera User Manual Appendix A: Device Command Scan the following QR code to get device common serial port commands. Note that the command list contains the commonly used serial port commands for all Hikvision network cameras. UM iDS-2CD7xxG0-xxxxx 021021NA...

  • Page 107: Appendix B: Device Communication Matrix

    Network Bullet Camera User Manual Appendix B: Device Communication Matrix Scan the following QR code to get device communication matrix. Note that the matrix contains all communication ports of Hikvision network cameras. UM iDS-2CD7xxG0-xxxxx 021021NA...
  • Page 108 iDS-2CD7xxG0-xxxxx Network Bullet Camera User Manual UM iDS-2CD7xxG0-xxxxx 021021NA...

This manual is also suitable for:

Ids-2cd7146g0-izsIds-2cd71c5g0-izsIds-2cd7046g0-apIds-2cd7a46g0-izhs8Ids-2cd7ac5g0-izhsy

Table of Contents

Save PDF
