Bronze 1.4
outside in the door phone the FT4SW or FT8SW offers the solution. These modules offer 4 and 8
extra relays safely in the house. Normally these relays are activated via the telephone keypad
forming the codes #001 for raly 1 up to #008 for relay 8.
But you can chose anyway to activate 1 relay of the FT4SW or FT8SW by forming the short code 2.
Code 2: use code 936ab where a= address FT4SW or FT8SW (if a=* the internal relay of the door
phone will be activated (default))
b= relay
attention: to be able to connect the FT4SW or FT8SW the plug in board FT29LON must be ordered.

12. Setting max. conversation time

This setting sets the maximum conversation time. After this time the Wizard will end the
conversation automatically.
This conversation time can be set in steps of 5 seconds and can be multiplied by 01 to 99.

How ?

Code value to be set
80 xx
Code 80 00 maximum conversation time (60 minutes)
Code 80 24 conversation time 24 x 5 seconds= 2 minutes (default)
Code 80 50 conversation time 50 x 5 seconds = 250 seconds or 4 minutes, 10 seconds.

13. Setting push time button

This setting allows you to settle the push time needed before the call will be made.
Remark: only for the models without key board.
How?
Code 931AB where AB stands for the number of steps of 0,1 seconds.
e.g 93101 = 100 msec (=default)
93110 = 1 second

14. Setting toggle/impulse contact

With this setting, you can choose between toggle (on/off) contact or impulse contact.
This setting is useful if you use the contact for operating the doorlock.
You can choose toggle if you want to operate an on/off switch
How ?
Code 6 10 Impulse contact (door lock)
Code 6 11 Toggle contact

15. Setting time (door) contact

This setting sets the time of the (door) contact.
FASTTEL Klipsenstraat 18A 9160 Lokeren
Tel : + 32 (0) 9 244 65 20 FAX:+ 32 (0) 9 244 65 29 Email: info@fasttel.com
Web : WWW.FASTTEL.COM
15 Bronze 1.4
When using the door contact, it is advised to activate the lock +/- one second.
Or you can operate a light and set a timer in 5 second steps.
These steps can be set from 01 to 99.
How ?
Code 81 00
Code 81 01
steps
Code 81 99
eg. Steps 5 seconds
eg. Steps 100 msec.

16. Setting contact steps 5 sec./100 msec.

You can set the contact in steps of either 5 seconds or 100 msec.
When using the doorlock it is advised that you set the contact in steps of 100 msec.
You can then set the code 81 xx to 10 (1 second).
If you choose to switch on a light, you can choose the 5 seconds steps.
You can then use the contact as a timer contact.
How ?
Code 5 20
Code 5 21

17. Setting loudspeaker level and micro sensitivity

This setting allows you to adjust the loudspeaker level and micro sensitivity to a default
level at the installation of the Wizard.
How ?
The installer sets the level via : code 88 XX
XX =value between 00 and 15.
8807 = default setting
8815 = highest loudspeaker level
8807 = medium loudspeaker level medium micro sensitivity (default)
8800 = highest loudspeaker level

18. Setting ID code

A DTMF ID code or Speech (option) can be set in the Wizard.
Tel : + 32 (0) 9 244 65 20 FAX:+ 32 (0) 9 244 65 29 Email: info@fasttel.com
contact not active
time duration one step (5 seconds or 100 msec.) consult setting contact
time duration 99 steps
8112 = 12 x 5 seconds = 60 seconds
8112 = 12 x 100 mseconds . 1200 msec.
contact in steps of 5 seconds max. = 99 x 5 sec. = 8 min. 15 sec.
contact in steps of 100 msec. max. = 99 x 100 msec. = 9.9 sec.
lowest micro sensitivity
FASTTEL Klipsenstraat 18A 9160 Lokeren
Web : WWW.FASTTEL.COM
16
