Fasttel Wizard Bronze Manual

Bronze 1.4
Manual
Wizard Bronze Wizard
The Ultimate Doorphone The Ultimate Doorphone The Ultimate Doorphone
FASTTEL Klipsenstraat 18A 9160 Lokeren FASTTEL Klipsenstraat 18
Tel : + 32 (0) 9 244 65 20 FAX:+ 32 (0) 9 244 65 29 Email: info@fasttel. Tel : + 32 (0) 9 244 65 20 FAX:+ 32 (0) 9 244 65 29 Email:
Web : WWW.FASTTEL.COM
1
Bronze
info@fasttel.com
Bronze 1.4
Product introduction
Congratulations with your Fasttel® Wizard Bronze. We are sure that this choice will answer
to all your demands in the area of doorphone systems. Please also browse through the
options and possibilities that Fasttel® can offer you.
The following products are available in the Wizard Bronze series:
Wizard 1 push button, Wizard 2 push buttons, Wizard 3 push buttons, Wizard 1 push button
+ access control key pad, Wizard 2 push buttons + access control key pad, Wizard 3 push
buttons + access control key pad, Wizard SAS for flexible built in applications. All these
models can be equipped with or without camera.
Options :
Datalink (I/O module) FT4SW or FT8SW with plug in FTLON
PC programmable module
Speech module 2 x 8 seconds
T.V. Twisted pair video UHF module
LCD built-in video monitor
LCD desktop model video monitor
Video on PC kit
Video over TCP/IP system
FT2100: image and speech on Apple/Android/Windows PC
Technical characteristics
Alimentation :18 AC – 1.16 A (24VDC if hardware version 9)
Camera : 0,2 lux (option)
Video : Twisted Pair (bv VVT, UTP, FTP,...) max 300 m..
Input : Analogue line – 600 Ohm
Door contact : 1 A – 24 Vac Dry contact
Dial tone detection : 425 Hz +/- 30 %
Busy tone detection : 500/500 Msec
Ring back detection : 1000/3000 msec.
Speech detection : 30 mV
Line current detection : < 25 m A > 17 Volt DC
VSWR : > 15 dB
Time out : Max. 60 minutes
Data out : optional LON module FT29LON
Comsumption : without camera 420 mA AC
: with camera 520 mA AC
