Summary of Contents for Fasttel WIZARD ELEGANCE IP

  • Page 1 Fasttel reserves the right to change the content without notice. Fasttel Belgium, Klipsenstraat 18A, 9160 Lokeren. Tel: +32 (0) 9244 65 20 info@fasttel.be Fasttel Netherlands, Heiligenboom 3, 5066 CB Moergestel. Tel +31 (0) 13 513 65 14 info@fasttel.nl Edition 1.4 pg1...

  • Page 2: Table Of Contents

    Content 1. Wiring diagram ..............................3 2. Wizard found in the network: ..........................3 3. Configuration ..............................3 3.1 log .................................. 4 3.2 Status................................4 3.3 Date and Time ............................... 4 3.4 Sip Connection Settings ..........................4 3.5 directory ................................ 6 3.6 Push-button settings .............................

  • Page 3: Wiring Diagram

    1. Wiring diagram The Wizard Elegance IP must be powered from a PoE network connection. If the existing network switch PoE not available then you order the best Fasttel PoE injector (FTPoE). 7 1 6 PoE LAN 1: common contact REL1...

  • Page 4: Log

    3.1 log Surf to the address of the Wizard and enter the default Username and Password. Both are admin. A second user login is in each case. If desired, change the language. You will see links to the configuration menu. 3.2 Status Here is a list of the values that you will soon need to configure yet.
  • Page 5 With screen name gives you a logical name for the device. Device location is useful when you have several door phones in one project. Phone number is the number of the door phone to the external Sipserver. Auth ID and password must be consistent with that data in the Sipserver.

  • Page 6: Directory

    Stop DTMF call: the call is forcibly terminated this code. Echo suppression options: this allows you best untouched. Press Apply to apply the changes. 3.5 directory Here is created: 1. The recipients who must be called. 2. And the people who need to access the optional keyboard entry. Nickname: 1.
  • Page 7 Time profile: You can assign a time profile of a recipient. Is this recipient rung outside the time profile of the door phone will launch a call or calls to the next destination that falls within a valid time profile. For example, you can program third shift teams among the first button, each with a different time profile of 8 hours of operation.

  • Page 8: Push-Button Settings

    3.6 Push-button settings This determines which recipients that you just created in the directory must be called when pushed by a push button. This page is license related: here there is only one button visible because a door phone was purchased with one pushbutton.

  • Page 9: Time Profile

    3.7 Time Profile Here, a time profile can be created which can be coupled under Directories to a recipient. Recipients are only called when the call is within the time profile. If no time profile is linked to a recipient, the call will always be launched. There are already preprogrammed second time profiles 4/5 and full-time (full week).

  • Page 10: Audio And Video Settings

    // IPADDRESS: 8080 / action = snapshot.jpg? You can enter this link blocking unauthorized by entering a user name and password. Note: when using the Fasttel FT25CC and some other phones that display picture the password feature should not be used.

  • Page 11: 3:10 Device Settings

    For audio codecs and video codecs you can make adjustments according to needs. 3:10 Device settings The Wizard Elegance IP is equipped with one RGB LED which, by means of a fiber optic technology, the right-hand portion illumines perfectly smooth. Here you can set the color of the LED and thus your Elegance.

  • Page 12: 3:11 Configuration Settings

    3:11 Configuration settings On delivery the unit is in DHCP mode. With a progamme as "advanced ip scanner" (http://www.advanced-ip-scanner.com/nl/) You can scan the network and if there is a DHCP server running, you will find the device name Fasttel000551XXX and shows the resulting IP Address. (See point 2.

  • Page 13: 3:12 Account Settings

    With download configuration you can make a backup of the Wizard. When uploading, you can look for a backup and upload. Add language: Foreign languages can be added here. Contact Fasttel this. logThis is meant more for any error diagnosis by the manufacturer.

  • Page 14: 3:14 Software Update

    3:14 Software Update The latest firmware can be found on www.fasttel.com under downloads. Use the first option. 3:15 Autoprivisioning For use on call connect. 3:16 logout You will be logged off immediately. Edition 1.4 pg14...
