Click the SAVE button.
To edit fields in the Tunneled Networks section, select the relevant line in the table. In the
opened window, change the needed parameters and click the SAVE button.
To remove a subnet, select the checkbox located to the left of the relevant line in the table and click
the DELETE button (
After configuring all needed settings for the IPsec tunnel, click the APPLY button.
To edit the parameters of an existing tunnel, in the Tunnels section, select the relevant tunnel in the
table. On the opened page, change the needed parameters and click the APPLY button.
To disconnect an existing tunnel and establish it again, select the checkbox located to the left of the
relevant line in the table and click the RECONNECT button.
To remove an existing tunnel, select the checkbox located to the left of the relevant line in the table
and click the DELETE button (
To disable VPN tunnels based on IPsec protocol, click the DISABLE button.
). Also you can remove a subnet in the editing window.
). Also you can remove a tunnel on the editing page.
