Before You Begin:

Please read and make sure you understand all the prerequisites for proper installation of
your new ADSL Router. Have all the necessary information and equipment on hand
before beginning the installation.
Check Your Package Contents
If any of the above items are missing, please contact your reseller.
©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders.
owser
owser
, i.e
, i.e., ., ., ., .,
, i.e
owser, i.e
owser
, i.e
DSL-G604T Wireless ADSL Router
CD-ROM with Manual
Ethernet Cable
Telephone Cord
802.11g Antenna
12V AC, 1.2A Power Adapter
Software and specifications subject to change without notice. DSL-G604T.12062004
DSL-G604T
Wireless ADSL Router
Using a power
supply with a
different voltage rating
will
damage
product and void its
warranty.
this

Advertisement

Table of Contents
loading

Subscribe to Our Youtube Channel

Summary of Contents for D-Link DSL-G604T

  • Page 1: Before You Begin

    12V AC, 1.2A Power Adapter If any of the above items are missing, please contact your reseller. ©2004 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DSL-G604T.12062004 , i.e...
  • Page 2: Hardware Overview

    Hardware Overview Front Panel Power LED: Solid light indicates a connection to a good power connector. ADSL LED: Lights solid when sychronized with the ADSL connection. LAN Ports: A solid light indicates a connection on the associated port. A blinking light indicates activity on the associated port.
  • Page 3: Rear Panel

    LAN Ports: Your computers connect here using standard Ethernet cables. Reset Button: Resets the DSL-G604T to the factory default settings. Hold for seven seconds for the unit to factory reset. Power Receptor: The AC...
  • Page 4: Hardware Installation

    Hardware Installation Step a Step b Step a Step c...
  • Page 5 Hardware Installation (continued) Step a Connect the telephone cord from your phone jack to the ADSL port on the DSL-G604T. Step b Connect an Ethernet cable from your computer to a LAN port on the DSL-G604T. Step c Connect the power adapter to the power connector on the DSL-G604T and the other end to a known good power source.
  • Page 6: Using The Setup Wizard

    Using the Setup Wizard Step a Launch your Web browser (a shortcut is typically found on your desktop). Step b Type http://192.168.1.1 into the URL address box and press the Enter or Return key. Step c Admin is the default User Name and Password.
  • Page 7 Using the Setup Wizard (continued) Step e Click Next Step f This screen allows you to enter a new password for the admin account. This password is used to log into the web-based management interface. Click Next Step g Select your Time Zone Click Next...
  • Page 8: Dynamic Ip Address

    Click Next Step h1 Dynamic IP Address The DSL-G604T defaults to the most commonly used values in the United States. Note: If the MAC address does not appear, please refer to the User Manual on the CD-ROM.
  • Page 9: Static Ip Address

    Using the Setup Wizard (continued) Step h2 Static IP Address The DSL-G604T defaults to the most commonly used values in the United States. The IP address information on the right is only shown as an example of the format that you will use.
  • Page 10: Bridge Mode

    Using the Setup Wizard (continued) Step h4 Bridge Mode Click Next Step i Click Restart Step j Configuration is complete! Type in a URL such as www.dlink.com to test your connection.
  • Page 11 Appendix - Settings Checklist Your ISP has provided you one of the four methods listed on the right for connecting to the Internet. You may need to contact them to find out which method you are using and fill in the appropriate details.
