Creating PPPoE or PPPoA WAN Connection

On the connection creation page, in the General Settings section, select the relevant value from
the Connection type drop-down list and specify the needed values.
Figure 82. The page for creating a new PPPoE connection. The General Settings section.
Parameter
Interface
Connection name
Enable connection
General Settings
A physical interface to which the new connection will be assigned.
In order to create an Ethernet WAN connection, select the WAN
value or the value corresponding to the LAN port specified as the
WAN port.
In order to create an VDSL WAN connection, select the value
corresponding to the existing interface or the Add new PTM value
for creating a new interface at the physical layer.
In order to create an ADSL WAN connection, select the value
corresponding to the existing interface or the Add new ATM PVC
value for creating a new interface at the physical layer.
A name for the connection for easier identification.
Move the switch to the right to enable the connection.
Move the switch to the left to disable the connection.
Page 103 of 358
Configuring via Web-based Interface
Description
