MobileHelp Fall Button Complete User Manual page 5

Step 3. Turning ON your Base Station
Turn on your Base Station using the ON/OFF switch located on the back.
■
(Please refer to figure 5)
The display screen will turn on. (Please refer to figure 6)
■
The Emergency and Reset Buttons will illuminate.
■
If the Base is setup correctly, the Base Station will say "system ready" within 60 seconds.
■
Make sure your Base Station is connected to the cellular network by checking for the
■
signal strength bars on the display screen.
You can use the volume control buttons on the front of the unit at the bottom of the display
■
screen, indicated by the "–" or the "+" sign, to adjust if the voice is too loud or too soft.
Within a few minutes of turning on the system, the Cellular Base Station will obtain
■
the date and time from the cellular network and they will appear in the display area.
You are not able to set the date and time manually.
(01)00862262000453(11)170623(21)1234
Model Number: CBS4-01
ON/OFF
Manufactured For MobileHelp
This product contains;
Made in Malaysia
FCC ID: PXTCBS4-01
Switch
IC ID: 10876A-CBS401
CAN ICES-3(B)/
Figure 5
8
Figure 6
SRDR-00035 Rev. 1
Complete User Guide
Testing your In-Home Wireless System
Please test your system on a weekly basis using the TEST icon.
You can use the TEST button on your Cellular Base Station to conduct a test without speaking
to an Emergency Response Operator by following these steps:
- Press and hold the TEST button on Base Station until it illuminates green.
- You will hear an announcement over the Base Station that will instruct you to press the
Emergency Button or Pendant.
- Press the Neck Pendant or Wrist Button.
- The Base Station will announce "test call sent to Emergency Response Center".
- If your test was successful, you will hear "thank you for testing your device" from the
Base Station speaker.
- If your test was not successful, the Base Station will announce "user auto-test failed."
Please contact Technical Support.
The Base Station contains a battery backup. If you would like to test the battery
■
backup capability, please unplug the power for the Cellular Base Station from the AC
outlet. Then follow the testing steps above. Once you have finished testing, please
remember to plug the power back into the AC outlet.
SRDR-00035 Rev. 1
Complete User Guide 9
