MANUAL PART#: Q0581
PTO-X / ENGINE DRIVEN -
R
R R
GRASS COLLECTION SYSTEM
MODEL YEAR: 2020-Newer
OPERATOR'S MANUAL
ASSEMBLY
OPERATION
Z-Master 4000 Series
60" DECK
22651201
PTO-X
22651202
MAINTENANCE
Briggs & Stratton 6.5HP V
Initial Release- June 2021
