SAFETY WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or the vacuum collector adapter are fastened securely in place. WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower blades and the blower impeller have stopped rotating.
PECO elects, without charge if the defect appears within 90 days from the date of installation of such part or before the expiration of the original warranty period, whichever is later.
1-1 Introduction Rear Bumper Figure 2-1. We are pleased to have you as a PECO customer. Your collection system has been designed to give you a low maintenance, simple and effective way to collect the grass clippings from your mower. This manual is...
2-5 Aluminum Grass Container Fasten the main frame assembly to the mount brackets Installation using (2) 3/4”-10 x 1-1/2” hex bolts P#(K0364), (2) 3/4”- 10 nyloc nuts P#(K1433) and (2) 1/2”-13 handles P#(A1001) and 1/2”-13 x 1” HHCS P#(K1231). See NOTE: It is recommended that (3) people assist in Figure 2-3.
2-6 Dump Mechanism Adjustment 2-8 Engine Mount Arm Installation Insert the engine mount arm P#(A0318) into the outer The linkage may be adjusted in two places, at the motor mount tube P#(B1117) and fasten with (1) detent adjusting screw P#(K1435) and the latch assembly pin P#(J0248).
2-10 Blower Cone Installation 2-11 Impeller Blade Removal/Replacement Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of (2) 5/16”-18 x 2-1/2” HHCS P#(K0125). Now partially To Remove: First remove the center bolt (#1), washer thread the bolts into each of the two tabs located on the (#2) and spacer (#3) from the taper-lock bushing (#5).
2-12 Boot To Mower Deck Installation Figure 2-15. 7”-8” 5”-6” Inlet Clamp Clamp Fasten the boot plate P#(B0125) to the boot P#(E1128) using (2) 3/8”-16 x 1” carriage bolts P#(K1182) and (2) 3/8”-16 flange nuts P#(K1215). Remove the deflector pin that attaches the grass deflector to the mower deck. Mount the boot plate to the mower deck using the deflector pin as shown in Figure 2-12.
2-18 Throttle Cable Installation To install the throttle cable kit to the box assembly, align Figure 2-18d. the large end of the slot in the throttle base plate (Figure 2-18a) with the rivets located on the front of the box assembly frame (Figure 2-18b).
SECTION III 3-3 Disengagement Of The Blower OPERATING A. To disengage the blower, rotate the engagement INSTRUCTIONS handle towards the mower. 3-1 General Safety WARNING: The blower will continue to spin. DO NOT TOUCH the blower, pulleys, or the belt until the tractor is Only qualified people familiar with this operator’s manual turned off.
5-1 Parts And Service Information 1. Clean all debris from machine especially from the container, underneath the belt shields, and safety PECO collection system owners should record the name decals. Replace any missing or illegible decals. and telephone number of their Service Center. Your Service Center will be happy to supply replacement 2.
SAFETY DECALS To promote safe operation, PECO supplies safety decals on all products manufactured. Damage can occur to safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals. Part #: R4027 Part #: R1053...
