Familiar With The Radio - Retevis RB23 User Manual

Insert the top terminal vertexes of the battery into
the slots in the radio battery slot, then press the
bottom of the battery until hear the snap sound.
5. Install/Remove the back clip.
If necessary, the configured back clip can be locked on
the back of the battery by screw for easy carrying.
Unscrew two screws to remove the clip.

Familiar with the radio.

Antena
To remove the battery, please ensure that the
radio is off, and then push the battery latch button
at the bottom of the radio to the right. Remove the
upper part of the battery from the radio and
remove the battery.
6. Install the strap.
Slip the radio strap into the ring
in the middle of the radio.
Channel knob
Turn on/off knob/Volume knob
Indicator
Speaker/output voice
Mic/input voice
02
