Tripod Data Systems SURVEY PRO User Manual page 324

User's Manual – GPS Mode
No matching base found
3. Fill in the screen and tap Next>. The
base point name and the precise
geodetic coordinate of the base are
noted in Survey Pro. If you are doing
post processing at the base, the station
name, description, and antenna height
are then sent to the file on the base
receiver for post processing.
Set Up Rover
4. You are prompted to connect to the
rover receiver or will be automatically
connected if using Bluetooth. Once you
connect to the rover, it will begin to
monitor the data link for the base
corrections. You are then prompted to
enter the rover antenna height to
proceed with the setup.
The button at the bottom right of the
screen will say Next > any time this is
a remote rover setup, or if you have set
314
One matching base found
More than one matching base found
