Remote Elevation - Tripod Data Systems SURVEY PRO User Manual

and Rotation are correct before the Control Points screen is
opened. You need to select and occupy a single control point.
When you are done, tap Accept to return to the Solve Localization
screen and the calculated coordinates are returned to the North
and East fields.
9. Tap Solve>. Examine the results and tap Accept when you are
done. You will be prompted to name the new localization site and
save the record in the database.

Remote Elevation

If you set your base on a point with known elevation, you can begin
collecting data right away. However, if your base station is on a new
point, then you should calculate the elevation of the base and create
or update a vertical site before collecting new data. This can be done
in conjunction with horizontal localization, or you can use the Remote
Elevation screen.
•
The base and rover must be set.
•
You must be using a geoid model as part of your vertical
coordinate system.
• The horizontal coordinate system must be solved.
1. Open the Survey > Remote Elevation screen.
2. If your benchmark is not in the job file, select the Add Benchmark
checkbox, enter the Elevation, and specify a new point number in
the New Point field.
You can use the Remote Elevation screen to
occupy a vertical benchmark with the rover.
Applying the results of the occupation will
update the base point elevation and create a
new one-point vertical localization without
entering the Solve Localization wizard. This
procedure will not effect the horizontal
localization adjustment.
The following conditions must be met in order
to use the Remote Elevation routine.
GPS Module
259
