Rotate Adjustment

The Rotate Adjustment routine will rotate selected points around a
specified rotation point.
•
If you select Old and New Azimuths, enter an Old Azimuth and
New Azimuth in the appropriate fields. (The rotation angle
used is the computed angle from the old azimuth to the new
azimuth.)
5. Tap Solve. The selected points will be rotated around the
rotation point by the specified angle.
Other Conventional Surveying Tutorials
1. Tap Adjust , Rotate from the Main Menu.
2. Use the Tap Points... or To/From... button to
select the points that need to be rotated.
3. Enter the point that the selected points will
rotate around in the Rotation Point field.
4. Select a radio button for one of the
following rotation methods:
• If you select Simple Angle, simply enter
the rotation angle in the appropriate
field.
