Slope Staking the Road

The road slope staking procedure is nearly identical to the non-road
layout slope staking routine described on Page 131. The main
difference is the road layout templates can contain more segments,
which modifies the options of where the hinge point should be located
depending on if a cut or a fill is required.
Like with the road stakeout example above, this example describes
how to set up road slope staking and then refers you to the non-road
layout example where the screens are identical.
1. Tap Roads Slope Staking to open the Road Slope Staking screen.
2. Tap the Tap Road... button to open the Tap on a Road screen. All
of the roads that exist in the current job will be displayed.
3. Tap on the road that you want to stake and then tap
the road is selected, it will be drawn with a bold line.
4. If the backsight is not yet defined, tap the Backsight... button to
set up your backsight.
5. With the road selected, tap Next > to continue.
6. In the Station field, enter the station that you want to slope stake
and in the Station Interval field, enter the distance that you want
the Station to advance when you are ready to slope stake the next
station.
7. The H. Map and V. Map tabs are used to view information about
the horizontal and vertical details of the road at the current
station. Tap the Slopes tab to set up your slopes.
Road Layout
. When
93
