User's Manual – GPS Mode
you must setup the Windows Networking modem
parameters on the Data Modem card (see below).
Note: You do not need to select the RTK Correction Format for an
NTRIP rover because this will be determined by the NTRIP service
you pick at rover setup time.
•
Post Processing: Select this mode to use the receiver
to log data for post processing. You can do either
static or kinematic (stop and go) post processing data
collection control with Survey Pro. You do not need to
setup the data link parameters for post processing
receivers.
Receiver Settings – Data Modem
1. Select the specific type of data link in the Data Modem drop down
list.
2. Configure any settings required for this modem
Note: There are many different Data Modem types available. The
content of this drop down list will depend on the brand and model of
receiver selected. The settings to configure on this page will depend
on the specific Data Modem selected. If you are using a device that is
not listed in the Data Modem drop down, then you can choose to use
the 'Generic Serial' device and simply set the correct port, baud rate,
and parity for this device.
234
Select the RTK Correction Format if this is
o
required
Select any Rover Options if this is required
o
Select whether or not to use a CMR station
o
index for base or rover setup if this is
required.
Set the elevation cutoff desired for data
o
collection. This is the angle below which
satellites will not be used.
