User's Manual – GPS Mode
Starting a New Job: One Point Localization
Scenario
You show up at a new job site where no previous coordinates exist.
You want to use RTK to create a new ground level coordinate system
for a legal and topo survey.
Objectives
This tutorial job will teach you:
How to start a new job with one point and begin measuring ground
level distances without any existing control.
How to set the base and rover receivers
How to collect data points
How to check to existing points.
Procedure
1. Create a new job.
•
Enter Point Name 2 as the starting point and enter a starting
location of (5000, 5000, 100).
2. Set the base and rover.
•
Go to Start GPS Survey, choose
Start Survey with One Point Setup>.
• Choose Set New Base and 'connect' to the Demo Mode
receiver. A simulated autonomous base position is received,
and you can Set the base.
•
Connect to the Demo Mode rover, Set the Rover.
•
You are now ready to collect data in your new coordinate
system.
3. Data collect points 3,4,54, and CHAP.
4. Move the base receiver to a different setup.
• Go to Start GPS Survey, choose Set New Base.
