Translate Adjustment

The Translate routine will move points horizontally and/or vertically
a specified distance and direction. This routine is often used after a
survey was performed in an assumed coordinate system. If the actual
coordinates for at least one of the points is found later, the Translate
routine can be used to shift all of the affected points to the correct
coordinate system and/or elevation.
Other Conventional Surveying Tutorials
1. Tap Adjust , Translate from the Main
Menu.
2. Use the Tap Points... or To/From... button to
select the points that need to be adjusted.
3. Define the direction and distance for the
adjustment using either of the following
two methods:
