Overview
The IP-ACM Ethernet Door Module v2 module provides connection and management of access control for two readers.
The maximum number of IP-ACM Ethernet Door Module v2 modules supported per iSTAR Ultra is 32, iSTAR Ultra SE
is 32, and iSTAR Ultra LT is 8 or 16, depending on the model.
The maximum number of readers can be accomplished as follows:
■ iSTAR Ultra or Ultra SE (in Ultra Mode): Up to 16 IP-ACMs with 2 readers per IP-ACM, 32 IP-ACMs with 1 reader
per IP-ACM, or any combination of these configurations.
■ iSTAR Ultra LT 16-reader board (0312-7188-02): Up to 8 IP-ACMs with 2 readers per IP-ACM, 16 IP-ACMs with
one reader per IP-ACM, or any combination of these configurations.
For the 8-reader iSTAR Ultra LT board (0312-7188-01), you can have up to 4 IP-ACMs with 2 readers per IP-ACM, 8 IP-ACMs with
NOTE
one reader per IP-ACM, or any combination of these configurations.
The 16-reader iSTAR Ultra LT board has not been evaluated by UL.
The IP-ACM Ethernet Door Module v2 supports the following features:
■ 12VDC or 24VDC local power or Power over Ethernet (PoE or PoE+)
■ Two RJ45 ports:
• Port 1: Ethernet port, internally bound to MAC with the MAC address and used as the network connection port
for the board (10/100/1000)
• Port 2: Switch port, not a secondary port, used for iSTAR Ultra LT connection (10/100, no PoE).
Caution: Do NOT plug this port into the same network as J1 or a loopback will occur.
■ Four supervised Inputs and two Outputs
■ Communication to readers through Wiegand or RS-485 ports
IP-ACM Ethernet Door Module v2
Software House
Quick Start Guide
PART NUMBER: 8200-1466-01
VERSION: E0
SEPTEMBER 2019
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Johnson Controls Tyco 8200-1466-01
Summary of Contents for Johnson Controls Tyco 8200-1466-01
- Page 1 Software House IP-ACM Ethernet Door Module v2 Quick Start Guide PART NUMBER: 8200-1466-01 VERSION: E0 SEPTEMBER 2019 Overview The IP-ACM Ethernet Door Module v2 module provides connection and management of access control for two readers. The maximum number of IP-ACM Ethernet Door Module v2 modules supported per iSTAR Ultra is 32, iSTAR Ultra SE is 32, and iSTAR Ultra LT is 8 or 16, depending on the model.
-
Page 2: Requirements And Specifications
■ SSL network encryption from the unit to the GCM ■ IPv4 and IPv6 network protocols ■ 802.1X port-base authentication ■ HTTPS Web-based configuration ■ Offline mode for two readers that allows the last 1,000 previous card admits and/or a specific personnel group of no more than 100 Table 1: Part numbers and descriptions of IP-ACM Ethernet Door Module v2 and enclosures Part Number... - Page 3 ■ The anchoring system must be capable of sustaining, a proof load four times that of the assembly. Refer to the enclosure dimensions for information on the weight of enclosures. This weight does not include the cables. ■ The cables are protected by using metal or plastic conduit, or using flexible cable grip strain relief. ■...
-
Page 4: Environmental Requirements
Environmental requirements This product is for indoor use only and not intended for outside wiring as covered by article 800 in the National Electrical Code, NFPA 70. Table 3: Environmental requirements of the IP-ACM v2 Status Range Ambient temperature rating 32° to 120° F (0 to 49°C) Maximum elevation 6600 ft (2000m) Humidity... - Page 5 Not all configurations can detect all states. For more information regarding states, refer to the I/8-CSI User Guide and the con- NOTE figuration tables and images relevant to the configuration of your unit. IP-ACM Ethernet Door Module v2 power and wiring requirements Table 4 Page 5 describes the power and wiring requirements for the IP-ACM v2.
-
Page 6: Installation And Enclosures
Signal Power Requirements Shield Maximum Length Power over IEEE 802.3af (PoE) and 802at Switch Contact 328 ft. (100m) Ethernet (PoE) (PoE Plus), 25.5W max. LLDP supported for PoE Plus Local Power Maximum length depends on 12 or 24Vdc 25.5W application and AWG max. -
Page 7: Metal Enclosure
Plastic Enclosure Dimensions Item Dimension Height 7.2in (183mm) Width 12.1in (307mm) Depth 2.46in (62.4mm) Installing the plastic enclosure and IP-ACM Ethernet Door Module v2 To install the plastic enclosure, complete the following steps: 1. Remove the screws using the Software House security screwdriver (not included, part number: 132-183) and lift the enclosure cover off of the plastic enclosure. - Page 8 Figure 3: Metal enclosure mounting holes Installing the metal enclosure and the IP-ACM Ethernet Door Module v2 To install the module and metal enclosure, complete the following steps: 1. Open the door of the metal enclosure. 2. Secure the enclosure to selected wall or support surface using holes provided in the enclosure’s base. See Figure 3 Page 8 for dimensions and hole pitch for mounting.
-
Page 9: Switches And Jumpers
IP-ACM v2 Ethernet Door Module features Figure 4 Page 9 shows the switches, jumpers, ports, and connectors of the IP-ACM Ethernet Door Module v2. Figure 4: IP-ACM Ethernet Door Module v2 Switches and jumpers Figure 4 Page 9 for the locations of the switches and jumpers on the IP-ACM v2. Table 7 Page 9 describes the positions of switch SW1. -
Page 10: Ports And Connectors
SW2 used for factory reset Position D of rotary switch SW2 is used for factory reset. All other positions of the rotary switch are not used in this release. Factory reset 1. Switch the position of the rotary switch SW2 to position D. 2. - Page 11 Figure 5: Wiegand wiring for the IP-ACM v2 P5 and P6 You can wire these RS-485 ports either full or half duplex depending on the reader you are using. See Figure 6 Page for reference on wiring these RS-485 ports. Figure 6: Full duplex and half duplex wiring Wiring for the RS-485 ports are straight-through.
-
Page 12: Output Relay Wet Or Dry Jumpers
Inputs Figure 4 Page 9 for the four supervised inputs, P11 to P14, of the IP-ACM v2. Use standard Software House 1K dual EOL configuration. Further configurations may be selected through the IP-ACM v2 editor in C•CURE 9000. Output Relay Wet or Dry Jumpers The two output relays can be Dry or Wet, based on the position of these jumpers. -
Page 13: Normal Operation Mode
The following limitation applies to iSTAR controllers with member connected controllers and iSTAR Ultra controllers with connected IP-ACMs that use DHCP IP address assignments: ■ If DHCP is used, the lease may expire and assign a new IP address to the iSTAR controller. If this happens, all members and IP-ACMs are not able to connect to the iSTAR controller with the new IP address. -
Page 14: Standalone Configuration Mode
Standalone configuration mode To configure the IP-ACM v2 in Standalone mode, complete the following steps: 1. If there is no DHCP network, or the installer prefers configuring the IP-ACM v2 before putting it on the network, switch SW1-1 to ON. 2. Apply power using the PoE (J1) or the local power port. 3. - Page 15 Prerequisites ■ An Internet browser with JavaScript and cookies enabled. ■ IP-ACM v2 firmware version 04.01.00.30093, or greater. ■ A configured network switch with 802.1X capability. • Port control enabled: — Set the ports to be authorized to avoid authentication. —...
-
Page 16: Offline Configuration
a. If authentication fails due to an invalid configuration, move the Ethernet cable back to a non-authenticated port and re-configure the 802.1X settings that confirm to the radius server. b. A factory reset disables 802.1X and removes all configuration information. 9. -
Page 17: Door Configuration
Example: If you set the Maximum Cards Per Person value to 3, then only 1000 - 100 x 3 = 700 is allowed in the Admit the last admitted cards field for configuration. Door configuration In Offline Mode, all components of the door must come from the same IP-ACM v2 board. NOTE Door configuration in Offline Mode does not support RS-485 wiring for readers. - Page 18 Copyright and Trademarks ©2019 Johnson Controls. All rights reserved. JOHNSON CONTROLS, TYCO and C•CURE 9000 are trademarks and/or registered trademarks. Unauthorized use is strictly prohibited. Product offerings and specifications are subject to change without notice. Actual products may vary from photos.
