Technical Specifications

IOM2710 and IOM3710 Input/Output Modules
Product Code Numbers
Supply Voltage
Power Consumption
Ambient Conditions
Terminations
Controller Addressing
Communications Bus
Analog Input/Analog Output
Resolution and Accuracy
Mounting
Dimensions
(Height x Width x Depth)
Housing
Weight
Compliance
1. For more information, refer to the MS/TP Communications Bus Technical Bulletin (LIT-12011034).
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
MS-IOM2710-0
MS-IOM3710-0
20-30 VAC at 50 or 60 Hz, Class 2
10 VA typical, 14 VA maximum plus all BO and Configurable Output loads
Operating: 0 to 50°C (32 to 122°F); 10 to 90% RH noncondensing
Storage: -40 to 70°C (-40 to 158°F); 10 to 90% RH noncondensing
Screw terminals, 3-Position Screw Terminal Pluggable Blocks, 4-Position Screw Terminal
Pluggable Blocks
DIP switch set (4-127). Addresses 1-3, 128-255 are reserved.
BACnet® MS/TP; 3-wire FC Bus between the NAE/NCE and other devices. 4-wire SA Bus
when used as expansion to FEC.
Analog Input: 16-bit resolution
Analog Output: 16-bit resolution and ±200 mV in 0-10 VDC applications
On flat surface with screws on three mounting clips or a single 35 mm DIN rail
IOM2710: 180 x 127 x 58 mm (7-1/16 x 5 x 2-1/4 in.)
IOM3710: 180 x 127 x 58 mm (7-1/16 x 5 x 2-1/4 in.)
Plastic housing
Plastic material: ABS + polycarbonate UL94 5VB
IOM2710: 0.48 kg (1.1 lb)
IOM3710: 0.55 kg (1.2 lb)
United States:
UL Listed, File E107041, CCN PAZX, UL 916, Energy Management Equipment
UL Listed, File S4977, UL 864 UUKL/UUKLC 10th Edition Listed, Smoke Control Units and
Accessories for Fire Alarm Systems Equipment
FCC Compliant to CFR47, Part 15, Subpart B, Class A
Canada:
UL Listed, File E107041, CCN PAZX7, CAN/CSA C22.2 No. 205, Signal Equipment;
Industry Canada Compliant, ICES-003
UL Listed, File S4977, UL 864 UUKL/ORD-C100-13 10th Edition Listed, Smoke Control
Units and Accessories for Fire Alarm Systems
Europe:
CE Mark, EMC Directive 89/336/EEC, in accordance with EN 61000-6-3 (2001) Generic
Emission Standard for Residential and Light Industry and EN 61000-6-2 (2001) Generic
Immunity Standard for Heavy Industrial Environment and the Low Voltage Directive
73/23/EEC in accordance with EN 60730-1 (1999) Automatic electrical controls for
household and similar use.
Australia and New Zealand:
C-Tick Mark, Australia/NZ Emissions Compliant
BACnet International:
BACnet Testing Laboratories™ (BTL) 135-2004 Listed BACnet Application Specific
Controller (B-ASC)
IOM2710 and IOM3710 Input/Output Modules Installation Instructions
