Table A-2 Mini-GBIC Input/Output Port Specifications
Item
MGBIC-MT01
MGBIC-08
MGBIC-02

Gigabit Ethernet Specifications

The following specifications for the Mini‐GBICs (shown in Table A‐3 through Table
meet or exceed the IEEE 802.3z‐1998 standard.

MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)

Table A-3 MGBIC-LC01 / MGBIC-MT01 Optical Specifications
Item
Transmit Power (minimum)
Receive Sensitivity
Link Power Budget
Table A-4 MGBIC-LC01 / MGBIC-MT01 Operating Range
Item
62.5 µm MMF
62.5 µm MMF
50 µm MMF
50 µm MMF
Specification
Provides one MT-RJ fiber-optic multi-mode port that is compliant with
the 1000BASE-SX standard MT-RJ connector.
Provides one LC fiber-optic single-mode port that is compliant with the
1000BASE-ELX standard LC connector.
Provides one RJ45 copper connection that is compliant with the
1000BASE-T standard RJ45 connector.
62.5 µm MMF
-9.5 dBm
-17 dBm
7.5 dBm
Modal Bandwidth @
850 nm
160 MHz/km
200 MHz/km
400 MHz/km
500 MHz/km
Gigabit Ethernet Specifications
50 µm MMF
-9.5 dBm
-17 dBm
7.5 dBm
Range
2-220 Meters
2-275 Meters
2-500 Meters
2-550 Meters
SecureStack C2 Installation Guide A-3
A‐11)
