Installing the Switch on a Flat Surface
4. Remove the protective strip from the back of one rubber foot and position it on a
marked location and press firmly into place. Repeat this procedure to install the
remaining three rubber feet in the other three locations.
5. After installing the rubber feet, return the switch to its upright position.
6. Proceed to "Guidelines for Installation" on page 3‐8. For a rackmount installation,
proceed to "Rack Mounting the Switch" on page 3‐9.

Guidelines for Installation

Locate the switch within 152 cm (5 ft) of its power source and on a surface as shown in
Figure
to the 14‐pin Redundant Power Supply input connector on the rear of the switch, refer to
the installation guide shipped with the redundant power system.
The next step to install the switch is dependent on the type of installation. If installing
several switches in a stack, proceed to "Connecting High‐Speed Stacking Cables" on
page
RPS Power" on page 3‐15 for power connection instructions.
3-8 Hardware Installation
Note: If a number of switches are being installed in a stack, repeat steps 1 through 4 to
install the rubber feet on each switch before continuing with the installation.
3‐5. If an optional redundant power system is going to be installed and connected
Caution: To ensure proper ventilation and prevent overheating, leave a minimum
clearance space of 5.1 cm (2.0 in) at the left, right, and rear of the switch.
Do not connect the switch to the AC power source until instructed to do so later in the
installation process.
Precaución: Para asegurar una buena ventilación y evitar que el sistema se
sobrecaliente, deje un espacio mínimo de 5.1 cm (2 pulgadas) con respecto a los lados y
a la parte posterior del aparato
No conecte la fuente del poder a la fuente primaria hasta que no se le indique..
3‐11. If installing the switch as a standalone device, proceed to "Connecting AC and
