9E312-12 Module Specific Information

Module Interface Codes

The 9E312-12 Ethernet Switch Module has 15 interfaces. The table below lists the
identifying number, name, and description of each interface.
Use the numbers listed in Table 1 to configure the module's default interface (see the
General Configuration Screen).
2
Table 1. 9E312-12 Module Interface Codes
Interface Interface
Number Name
1 SMB1
2 SMB10
3 INB
4 ENET1
5 ENET2
6 ENET3
7 ENET4
8 ENET5
9 ENET6
10 ENET7
11 ENET8
12 ENET9
13 ENET10
14 ENET11
15 ENET12
Interface
Description
1 Mbps System Management Bus
10 Mbps System Management Bus
Internal Network Bus
Ethernet Front Panel Port 1
Ethernet Front Panel Port 2
Ethernet Front Panel Port 3
Ethernet Front Panel Port 4
Ethernet Front Panel Port 5
Ethernet Front Panel Port 6
Ethernet Front Panel Port 7
Ethernet Front Panel Port 8
Ethernet Front Panel Port 9
Ethernet Front Panel Port 10
Ethernet Front Panel Port 11
Ethernet Front Panel Port 12
