Module Interface Codes - Cabletron Systems 9G421-02 Appendix

9G421-02/9G429-02 Module Specific Information

Module Interface Codes

The 9G421-02 and 9G429-02 modules have 7 interfaces each. Table 1 lists the
identifying number, name, and description of each interface.
Interface
Number
1
2
3
4
5
6
7
Use the numbers listed in Table 1 to configure the module's default interface (see
the Figure 1, the General Configuration Screen).
2
Table 1. 9G421-02/9G429-02 Module Interface Codes
Interface
Name
SMB1
SMB10
HOST
LOCAL
INB
ENET1
ENET2
Interface
Description
1 Mbps System Management Bus
10 Mbps System Management Bus
i960 Host
i960 Controller
Internal Network Bus
Gigabit Ethernet Front Panel Port 1
Gigabit Ethernet Front Panel Port 2
