Summary of Contents for Logik L7SPDVD16
- Page 1 Instruction Manual 7˝ Portable DVD Player L7SPDVD16 L7SPDVD16_IB_Final171221V6.indd 1 21/12/2017 3:13 PM...
- Page 2 L7SPDVD16_IB_Final171221V6.indd 2 21/12/2017 3:13 PM...
-
Page 3: Table Of Contents
Contents Safety Warnings ............................. 5 Unpacking .............................. 7 Product Overview ..........................8 Front View .....................................8 Right Side View ...................................9 Remote Control ............................10 Removing the Insulating Strip from the Remote Control ..............12 Battery Installation for the Remote Control ..................12 How to Swivel the Display ........................13 Swivel Mode ..................................13 Handheld Mode ................................13 Remote Control Operation Range ......................14... - Page 4 Zoom Selection ................................23 TITLE ....................................23 MENU ....................................23 Customising the General Settings......................23 Customising the Audio Settings ......................25 Customising the Video Settings ......................26 Customising the Preference Settings ....................26 Customising the Password Settings ....................28 Maintenance ............................29 Hints and Tips ............................30 Specifications ............................32 L7SPDVD16_IB_Final171221V6.indd 4 21/12/2017 3:13 PM...
-
Page 5: Safety Warnings
Safety Warnings Ventilation • Read all the instructions carefully before using the unit and keep them for future • To prevent the risk of electric shock or reference. fire hazard due to overheating, ensure • Retain the manual. If you pass the unit that curtains and other materials do not onto a third party make sure to include this obstruct the ventilation vents. - Page 6 Earphones Supervision • Listening to loud sounds for • Children should be supervised to ensure prolonged periods of time may that they do not play with the unit. permanently damage your hearing. • Never let anyone especially children push • Before putting on earphones, turn the anything into the holes, slots or any other volume down then put the earphones on openings in the case - this could result in a...
-
Page 7: Unpacking
Thank you for purchasing your new product. These operating instructions will help you use it properly and safely. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. Read all the safety instructions carefully before use and keep this instruction manual for future reference. -
Page 8: Product Overview
Product Overview Front View 1. LCD Display Power Indicator Light up red when the unit is 2. Speakers turned on. OPEN Button 7. Disc tray cover Press to open the disc tray cover. 8. VOL – / VOL + Button Battery Charging Indicator Increase or decrease the volume. -
Page 9: Right Side View
Right Side View ON OFF DC IN 9-12V AV OUT SETUP SOURCE PLAY / PAUSE Button Earphones Socket Start/pause/resume playback of a disc. 6. AV OUT Socket 2. SETUP Button 7. ON/OFF Switch Press to display/exit from GENERAL 8. DC IN 9-12V Socket SETUP PAGE. -
Page 10: Remote Control
Remote Control 1. STEP Button Frame Advance in DVD mode. 2. SEARCH Button STEP MUTE SOURCE To search and start playback from a selected point on the disc. 3. 0-9, 10+ Number Buttons Create programs or locate a title/chapter/ track or specific time. DISPLAY 4. - Page 11 13. SOURCE Button Select among the different input sources: DVD / USB / Memory Card. STEP SOURCE MUTE 14. MUTE Button To mute or restore your DVD sound output. 15. DISPLAY Button Display the playtime and show status DISPLAY information on the screen. SUBTITLE AUDIO MENU...
-
Page 12: Removing The Insulating Strip From The Remote Control
Removing the Insulating Strip from the Remote Control Remove the plastic strip from the battery if the battery is being used for the first time. It is located at the bottom back side of the remote control. Battery Installation for the Remote Control The remote control requires a CR2025, 3V Lithium battery. -
Page 13: How To Swivel The Display
• Do not dispose of the used battery as domestic waste. Dispose of it in accordance with the local regulations. • Small button cell batteries such as the one used in the remote control are easily swallowed by young children and this is dangerous. Keep loose button cells away from young children and make sure that the battery holder tray is secure in the remote control. -
Page 14: Remote Control Operation Range
Remote Control Operation Range Point the remote control at the unit no more than 2 metres from the remote control sensor and within 40° of the front of the unit. The operating distance may vary depending on the brightness of the room. 20°... -
Page 15: Charging The Battery
Charging the Battery 1. Connect the mains adapter (included) to the DC IN socket at the right side of the unit and then connect the mains adapter to a mains socket. a) The Battery Charging Indicator flashes to indicate that the battery is charging. When the battery is charged to full capacity, the Battery Charging Indicator lights up green. -
Page 16: Connections
Connections Connecting to a TV If your TV has audio/video inputs, you can connect the unit to your TV with a 3.5mm to RCA AV Converter (included) and a RCA AV Cable (not included). DVD Player Right Side AV OUT ON OFF DC IN 9-12V SETUP... -
Page 17: Using A Usb Device
Using a USB Device General Operation You can play or view picture files (JPEG) or music files (MP3) from a USB device. Step Action DVD Unit / Remote Control Connect the USB device to the USB slot. SETUP SOURCE AV OUT ON OFF DC IN 9-12V Press SOURCE to access the data in the... -
Page 18: Compatible Disc Types
Press SOURCE. SETUP SOURCE AV OUT ON OFF DC IN 9-12V Press SOURCE to access the data in the device. Press to highlight DVD, and AV OUT ON OFF DC IN 9-12V SETUP SOURCE the press to confirm. The DVD player will return to disc mode –... -
Page 19: Region Code
1. Slide the ON/OFF switch to ON position on the side panel to turn the DVD player on. 2. The LOGIK DVD logo (start-up picture) will appear on the screen and the unit will start loading the disc automatically (if available). -
Page 20: Basic Dvd Playback
Basic DVD Playback 1. Make sure the unit is either plugged into the power socket through the mains adapter or the battery is fully charged. 2. Slide the ON/OFF switch to the ON position. 3. Press the OPEN button to open the disc cover. 4. -
Page 21: Stop Playback
Stop Playback 1. Press the button on the remote control to go to pre-stop mode, the display will show “ ”. With some discs, the unit can recall the stopped location, such as on DVDs. 2. Press the button on the unit or the remote control to resume playback from the location where playback was stopped or from the beginning of the disc. -
Page 22: Slow
Slow Press the SLOW button on the remote control when a DVD is playing to enter slow playback. Each time you press the SLOW button on the remote control, the playback speed changes in the following sequence: 1/16 Normal 1/16 Angle Selection Some DVDs contain scenes which have been shot from a number of different angles. -
Page 23: Programmable Memory
Programmable Memory DVD, CD • Press the PROGRAM button on the remote control to display the PROGRAM MENU. Press the 0-9, 10+ buttons on the remote control to input the title/chapter/track number and then press the buttons to select START. • To resume normal playback, press the PROGRAM button and buttons on the unit or remote control to select STOP. - Page 24 3. Press the buttons to select the following options and then press the buttons to change the setting. TV DISPLAY To select the aspect ratio of the playback picture. 4:3 PANSCAN If you have a conventional TV and want both sides of the wide picture to be trimmed or formatted to fit your TV screen.
-
Page 25: Customising The Audio Settings
Customising the Audio Settings 1. Press the SETUP button to display the setup menu. - - AUDIO SETUP PAGE - - buttons to select AUDIO 2. Press the DOWNMIX SETUP PAGE. DOLBY DIGITAL GOTO AUDIO SETUP PAGE 3. Press the buttons to select the following options and then press the buttons to change the setting. -
Page 26: Customising The Video Settings
Customising the Video Settings 1. Press the SETUP button to display the setup menu. - - VIDEO SETUP PAGE - - buttons to select VIDEO 2. Press the BRIGHTNESS SETUP PAGE. CONTRAST COLOUR GOTO VIDEO SETUP PAGE 3. Press the buttons to select the following options and then press the buttons to change the setting. - Page 27 AUDIO Allows you to choose the preferred audio language of your disc. If the preferred language is not available on the disc, the DVD player will automatically use the DVD disc’s default language. SUBTITLE Allows you to choose the preferred subtitle language of your disc. If the preferred language is not available on the disc, the DVD player will automatically use the DVD disc’s default language.
-
Page 28: Customising The Password Settings
Customising the Password Settings 1. Press the SETUP button to display the setup menu. - - PASSWORD SETUP PAGE - - 2. Press the buttons to select PASSWORD MODE PASSWORD SETUP PAGE. PASSWORD GOTO PASSWORD SETUP PAGE 3. Press the buttons to select the following options and then press the buttons to change the setting. -
Page 29: Maintenance
Maintenance Handling Discs • Do not touch the playback side of the disc. • Do not attach paper or tape to the disc. Playback side Cleaning Discs • Fingerprints and dust on the disc cause picture and sound deterioration. Wipe the disc from the centre outwards with a soft cloth. -
Page 30: Hints And Tips
Hints and Tips If a problem does occur, it may often be due to something very minor. The following table contains various tips. SYMPTOM CAUSE / SOLUTION No power. • Ensure the car power adapter or the mains adapter is connected. • Make sure that the unit is turned on. - Page 31 SYMPTOM CAUSE / SOLUTION The disc does not • There is no disc inside the unit (“NO DISC” appears on the play. display). • Insert the disc correctly with the graphics facing up. • Clean the disc. • A non-valid disc has been inserted, or the disc region number does not match the region number of the unit.
-
Page 32: Specifications
Specifications L7SPDVD16 Model Power Adapter (Use only power adapter listed below) Mains Adapter Power Adapter Manufacturer Mass Power Power Adapter Model PEA-090100VG Input AC 100-240V, 50/60Hz Output DC 9 V, 1.0 A Car Power Adapter Manufacturer Shenzhen Weirunda Company Co., Ltd... - Page 33 Feature Decoding Format CD, CD-R, CD-RW, MP3, JPEG, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW Video System PAL, NTSC Connectivity USB Port 2.0 × 1, AV Out Socket × 1, Earphones Socket × 1, DVD Tray × 1 Dimension (W) × (D) × (H) 176.5 ×...
- Page 34 L7SPDVD16_IB_Final171221V6.indd 34 21/12/2017 3:13 PM...
- Page 35 L7SPDVD16_IB_Final171221V6.indd 35 21/12/2017 3:13 PM...
- Page 36 All trademarks are the property of their respective owners and all rights are acknowledged. DSG Retail Ltd. (co. no. 504877) 1 Portal Way, London, W3 6RS, UK IB-L7SPDVD16-171221V6 L7SPDVD16_IB_Final171221V6.indd 36 21/12/2017 3:13 PM...
