Lima - Corner TV Unit
Assembly Instructions -
Dimensions
Width - 79.5cm
Depth - 39cm
Height - 51cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
276/4296
MADE IN
BRITAIN
Issue 1 - 01/07/14
Advertisement
Related Manuals for Argos Lima
Summary of Contents for Argos Lima
- Page 1 Lima - Corner TV Unit Assembly Instructions - 276/4296 Please keep for future reference Dimensions Width - 79.5cm Depth - 39cm MADE IN Height - 51cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 14kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Horizontal (D1315A) (D1318A) (795 x 391mm) (721 x 352mm) Plinth (D1320A) (721 x 96mm) Side...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the holes shown on the back of the drawer front Note: Tighten metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 7 Prepare the left side Place a runner onto one of the sides Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 8 Assembly Instructions Step 8 Prepare the right side Place a runner onto one of the sides Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 9 Assembly Instructions Step 9 Prepare the top Screw 2 metal dowels into the top Screw 4 small metal dowels into the holes on the top Note: Tighten metal dowels up fully against the panels. Step 10 Join the top to a side Attach the top to the right side...
- Page 10 Assembly Instructions Step 12 Fit a horizontal Push a horizontal onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the horizontal Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
- Page 11 Assembly Instructions Step 15 Fit the plinth Push the plinth onto the right side Use a screwdriver to tighten the large locking fitted to the plinth Note: Turn the large locking nut as far as it will go - more than 1/2 a turn.
- Page 12 If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3075...
