Yani 4' , 4'6"and 5' Bed to Go
Assembly Instructions
Dimensions (4')
Length - 201cm
Width - 129cm
Height - 105cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
– Please keep for future reference
Dimensions (4'6)
Length - 201cm
Width - 144cm
Height - 105cm
Dimensions (5')
Length - 211cm
Width - 159m
Height - 105cm
616/7129
606/9234
619/3571
621/9204
622/6242
621/7828
Issue 1 - 27/09/16
