Wow Lima Dining Table
600/6503
Assembly Instructions
- Please keep for future reference
600/6510
Dimensions
Width - 90cm
Depth - 90cm
Height - 75.5cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 01/04/13
Advertisement
Related Manuals for Argos Wow Lima 600/6503
Summary of Contents for Argos Wow Lima 600/6503
- Page 1 Wow Lima Dining Table 600/6503 Assembly Instructions - Please keep for future reference 600/6510 Dimensions Width - 90cm Depth - 90cm Height - 75.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 01/04/13...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Do not discard any of the • Discard all extra fittings and • We do not packaging until you have keep fittings out of reach of recommend the checked that you have all the children.
-
Page 3: Components - Parts
Components - Parts Please check you have all the parts listed below Table top Middle brace (90 x 90 x 2cm) (1.3 x 1.3 x 30.5cm) holes higher holes lower Leg A x 2 Leg B x 2 (44 x 2.5 x 75cm) (44 x 2.5 x 75cm) Components - Fittings If you have damaged or missing components,... - Page 4 Assembly Instructions Step 1 Assembling legs A Identify the correct legs for assembly & with the help of an assistant attach the legs A middle brace using bolts and nuts Important: Fasten bolts & nuts using allen spanner but do not fully tighten at this stage.
- Page 5 Assembly Instructions Step 3 Attaching rails Place the table top upside down on a flat protected surface. Position the legs & on the table top shown and fix using bolts Important: After fully tightening bolts fully tighten all bolts & nuts assembled on step 1.
- Page 6 Lima Dining Chair 600/6503 Assembly Instructions - Please keep for future reference 600/6510 Dimensions Width - 42cm Depth - 42cm Height - 85.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 13 /03/13...
- Page 7 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Do not discard any of the • Assemble all parts loosely • We do not packaging until you have before tightening any bolts. recommend the checked that you have all the use of power •...
- Page 8 Components - Parts If you have damaged or missing components, call the Customer Helpline: 08456 400800 Please check you have all the parts listed below Upper leg Lower leg Backrest (54.5 x 3 x 59cm) (54.5 x 3 x 59cm) (32.5 x 5 x 39.5cm) Seat (38.5 x 38.5 x 4cm)
- Page 9 Assembly Instructions Step 1 Attaching backrest Position the upper leg and lower leg in a crossed position as shown. With the help of an assistant holding the legs, insert the legs into holes on the backrest as shown. Then fix through holes using bolts and tighten with allen key...
