Lucas - Desk
Assembly Instructions -
Dimensions
Width - 100cm
Depth - 45cm
Height - 72cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
247/3965
247/4476
247/6399
MADE IN
BRITAIN
Issue 1 - 01/04/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Lucas 247/3965
Summary of Contents for Argos Lucas 247/3965
- Page 1 Lucas - Desk Assembly Instructions - 247/3965 Please keep for future reference 247/4476 247/6399 Dimensions Width - 100cm Depth - 45cm MADE IN Height - 72cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 01/04/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 19kgs. Please lift space to layout the parts before recommend the with care. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Upright Right Side (D2911A) (D2912A) (D2913A) (706 x 394mm) (706 x 394mm) (706 x 394mm) Base...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front and drawer wrap Screw 2 metal dowels into the holes shown on the back of the drawer front Note: Tighten the metal dowels up fully against...
- Page 6 Assembly Instructions Step 3 Attach the drawer stops Carefully break off the 2 drawer stops (F599) from the pair of drawer runners Push the drawer stops fully through the drawer F599 wrap from the inside. F599 F599 F599 Step 4 Attach the handle Attach the handle the drawer front using 2...
- Page 7 Assembly Instructions Step 6 Prepare the left side and the upright F600 Separate the runners Push fit left runner marked ‘L’ into the holes shown on left side Note: Runners must be be fitted flat against the Finished panel. If necessary front edge gently tap into final position.
- Page 8 Assembly Instructions Step 7 Fit the base to the upright Attach the base the upright using 2 screws Finished front edge Step 8 Prepare the plinth Tap 2 wooden dowels into the plinth 10mm Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
- Page 9 Assembly Instructions Step 10 Fit the left side Attach the left side the base and plinth using 3 screws Step 11 Prepare the right side Insert 2 large locking nuts into the right side Finished front edge Step 12 Finished top edge Fit the modesty 2 people are needed...
- Page 10 Assembly Instructions Step 13 Fit the right side and the plastic nails 2 people are needed here Attach the right side to the modesty using 2 screws Tap 2 plastic nails into the bottom edge of the left side , upright and right side Step 14 Prepare the top panel...
- Page 11 Assembly Instructions Step 15 Fit the top Push the 6 metal dowels fitted to the down into the holes in the top edge of the side and upright panels. Use a screwdriver to tighten the 6 large locking nuts fitted to the side and upright panels Note: Turn the large...
- Page 12 Lift with care. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2989...
