Toddler Bed

Dimensions

Width -75 cm
Depth - 145cm
Height - 57cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
- Please keep for future reference
707/3676
723/9939
Issue 4 - 04/04/17
