- Page 1 SUBMERSIBLE PUMPS MODEL NO: HSE RANGE PART NO: SEE TABLE PAGE 13 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0921 - rev 9...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE heavy duty submersible pump. Before attempting to use the pump, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to the submersible pump giving you long and satisfactory service.
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS GENERAL PUMP SPECIFIC 1. Read all instructions before use 1. Do not pump explosive / and save these instructions for flammable liquids or chemicals. future use. 2. Never allow the pump to run dry 2. An approved residual current or operate out of the water. -
Page 4: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Models EXCEPT HSE301A & 361A should have their mains lead connected to a standard 230 volt (50Hz) electrical supply through an approved plug or a suitably fused isolator switch. -
Page 5: Fuse Rating
• The YELLOW AND GREEN wire must be connected to the terminal which is marked E or coloured green. The HSE301 & 361 must be connected to a protected 110V supply through a suitably approved connector. On no account must a 230V, 13amp plug be used. - Page 6 OVERVIEW The Clarke HSE range of submersible pumps are of rugged and durable construction, designed for long lasting continuous operation. They are suitable for discharging pools, ponds, fountains, pits and any waste water drainage. They can handle foul water containing sewage or other suspended material...
-
Page 7: Operation
• It is not recommended that these pumps be used for pumping drinking water, as there is a remote possibility of water contamination due to leakage of pump lubricant should the pump malfunction or the oil seal become damaged. All HSE pumps are provided with a thermal overload cut-out, so that in the event the pump becomes overheated (due to becoming blocked etc.) the pump will shut off automatically. -
Page 8: Automatic Thermal Overload
(at least 5 minutes) before attempting to restart, by which time the cut- out will have reset. ACCESSORIES A wide range of accessories is available from your nearest CLARKE dealer, for further information, contact your nearest dealer, or telephone CLARKE International Sales department on 01992 565300. - Page 9 HSE SERIES PUMP PERFORMANCE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 10: Cleaning And Maintenance
MAINTENANCE. This pump should require no maintenance other than regular cleaning. If the pump starts to show signs of wear or damage, contact your CLARKE dealer for advice. Do not use the pump if there is any damage to the mains power cable, or to the float switch or it’s connecting cable. -
Page 11: Fault Finding
7. Water level too low - float switch in OFF position - lift float to check switch. 8. If the pump still fails to start, consult your CLARKE dealer for advice. PUMP WILL 1. Check that the inlet is not blocked. -
Page 12: Parts Diagram
PARTS DIAGRAM 1 Top cover Pump Casing 2 Upper Bearing Strainer 3 Motor Housing 14 Power Cable 4 Shaft 15 Capacitor 5 Stator 16 Cap Packing 6 Lower Bearing 17 O-ring 7 Seal Plate 18 O-ring 8 Oil Seal 19 Nut 9 Mechanical Seal 20 Setting Screw 10 Seal Cover... -
Page 13: Technical Specifications
TECHNICAL SPECIFICATIONS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 14 DECLARATION OF CONFORMITY-UK Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 15: Declaration Of Conformity-Eu
DECLARATION OF CONFORMITY-EU Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
