DESCRIPTION OF THE TERMS

In the designation of the POWERLOCK BOX technical terms or abbreviations of
technical terms can be found which are listed and described here.
Contact type PD Power Drain: Connector equipped with a "female" contact in a
"male" housing. The contact body is fitted with a spring-loaded insulated cap to
prevent contact.
This type is usually connected on the non-current carrying side
Contact type PS Power Source: Connector equipped with a "male" contact in a
"female" housing. The contact body is fitted with an insulated cap to prevent con-
tact.
This type is usually connected on the side of the power source.

Fig. 1: Connecting Uses
