Connection Connector Powerlock; Fig. 17: Connection Powerlock Connector (Eu Coding) - ITT POWERLOCK BOX Translation Of The Original Operating Instructions

CONNECTION CONNECTOR POWERLOCK

The connection is made by sequentially plugging the connectors in the correct or-
der (PE, N, L1, L2, L3). The connectors have a bayonet locking mechanism.

Fig. 17: Connection POWERLOCK connector (EU coding)

Page 32 of 40
COMMERCIAL. RESTRICTED TO EMBARGOED COUNTRIES AND DENIED PARTIES.
PRINTED COPIES ARE NOT MAINTAINED TO LATEST REVISION.
INFORMATION!
Before connecting the POWERLOCK connectors, make sure
that the rated current of the cables and connectors used cor-
responds to that of the POWERLOCK BOX and the power con-
ductors.
Only genuine ITT Powerlock connectors may be used with this
junction box. The use of non-approved connectors may cause
damage to the box and will void any warranty.
When using variants of the POWERLOCK BOX with cover, the
cover must first be opened with the enclosed square key.
Operating Instructions POWERLOCK BOX Rev. -
