MIM Performance View

SIRM and MRXI Hubs

SIRM and MRXI Hubs
The Performance View for the SIRM and the MRXI modules provides the
following information:
Model Name
The user-defined or default name of the hub model.
Network Address
The network IP address (e.g., 132.177.118.24).
MIM Name
The name of the module.
MIM Type
The type of module (i.e., IRM2).
Slot Number
The number of the hub slot that contains the module.
Ports On Out Of
The number of operating ports on the device out of the total number of ports.
Standard Statistics
This button allows you to access the MIM Standard Statistics View. The MIM
Standard Statistics View displays two bar gauges at the bottom of the view,
displaying information on Packets and Collisions. The right box (green
number) and the bar gauge show the number of packets/collisions since the
last poll. The left box (white number) shows the number of packets/collisions
measured since the module was powered up. The Packets and Collisions
buttons display rate graphs for each statistic.
Config Alarms
This button allows you to access the MIM Configure Alarms View, which
allows you to set threshold alarms and enable them. Table 6-6 displays the
information contained in this view.
Table 6-6. SIRM and MRXI MIM Configure Alarms View Fields
Model Name
Network Address
MIM Name
Performance Views
6-10
Field
The user-defined name of the MIM model.
The IP address of the device.
The name of the MIM device.
Description
