Table 6-9. Ethernet Port Standard Statistics View Field Definitions
Model Name
Network Address
MIM/Port Number
Packets
Collisions

MRXI Hub

The Port Performance View for the MRXI hub displays information related to
the status of the port. The information in this view includes:
Model Name
The user-defined or default name of the hub model.
Network Address
The network IP address (e.g., 134.141.256.145).
MIM/Port Number
The MIM (the slot in the hub) number and the port number in this format: 1.1
(Port 1, Slot 1).
Port Media Type
The type of cables that can be connected to this port.
Port Status
The network state of this port.
Port Link Status
The state of the link signal for this port.
Port Admin State
The administrative state of this port (off or on).;
9030367 E7
Field
The user-defined or default name of the model.
The network IP address (e.g., 134.141.256.145).
The MIM number and the port number, in this format: 1.1
(MIM/slot 1, Port 1).
The number of packets this port has seen since the last
reset. The white number is the total number, the green
number and the horizontal bar gauge are the number since
the last poll. The button opens a view that displays a graph
showing the rate of change and the value of the graph at
the last poll.
The number of collisions this port has seen since the last
reset. The white number is the total number, the orange
number and the horizontal bar gauge are the number since
the last poll. The button opens a view that displays a graph
showing the rate of change the value of the graph at the
last poll.
Port Performance View
Definition
Performance Views
MRXI Hub
6-17
