Configuration View Description
Redundancy View
Flash Download View
You can access the Flash Download View by clicking on the Flash Download
button in the Configuration View. This view is available only for the IRM3, the
MRXI, and the MiniMMAC hubs. The Flash Download View displays the
following information:
Model Name
The user-defined or default name of the hub model.
Network Address
The network IP address (e.g., 132.177.118.24).
Last Image Filename
The filename of the last image to be loaded into flash memory successfully.
Last Server IP Address
The IP address of the file server used to load the image presently in flash
memory.
Flash Size in Bytes
The size in bytes of the flash memory contained in the module.
Flash Count
The number of times that the flash memory has been reprogrammed. This
value is initialized to 1 upon initial power up of the device.
Firmware Base Address
The starting address of the firmware in RAM.
Firmware Top Address
The ending address of the firmware in RAM.
Firmware Start Address
The jump address of the firmware in RAM as established by the boot process.
DownLoad Software
This button allows you to access the DownLoad Software View. This view
allows you to upgrade the hub's firmware from a TFTP Boot Server.
Table 4-6describes the fields provided by this view.
Table 4-6.
DownLoad Software View Field Definitions
Model Name
Network Address
Configuration Views
4-14
Field
The user-defined or default name of the hub model.
The network IP address (e.g., 132.177.118.24).
Definition
Cabletron Ethernet Hubs
Management Module Guide
