MMAC Device Panel
Table 2-1. Logical Gauge Menu Options
Option
Frames
Bytes
Recv_Colls
Trans_Colls
Total_Errors
Align_Errors
CRC_Errors
Runts
Giants
OutOfWindow
Table 2-2. Gauge Mode Menu Options
Option
Percentages
Rates
Device Views
2-6
Definition
Indicates frames received or transmitted by the module
or port.
Indicates bytes received or transmitted by the module
or port.
Indicates collisions detected by the module or port
while receiving data.
Indicates collisions generated by the module or port
during transmission.
Indicates errors detected by the module or port.
Indicates misaligned packets detected by the module or
port.
Indicates packets with bad Cyclical Redundancy
Checks (CRCs) received by the module or port.
Indicates runt packets received by the module or port.
Runt packets are packets that are less than the
standard Ethernet frame of 64 bytes, not including
preamble.
Indicates giant packets received by the module or port.
A giant packet exceeds 1518 bytes not including
preamble.
Indicates collisions out of the standard window (51.2 s)
due to a network problem.
Definition
Displays the selected statistic as a percentage of the
total statistics for the module.
Displays the selected statistic as a rate over a given
time frame.
