Hercules
18ft X 20ft
™
17ft9in Wide x 20ft Deep x 6ft8in Side Height /
11ft6in Center Height
King Canopy Item #: HC1820PC
With 8 Legs, White Drawstring Cover,
Elastic Ball Straps & Foot Pads.
WARNING:
Keep all flame and heat sources
away from this tent fabric. Meets
the flammability requirements of
CPAI-84 Sec 6 and NFPA 701. It is not
fire proof. The fabric will burn if left in
continuous contact with any flame source.
www.northlineexpress.com
1-877-734-2458
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KING CANOPY Hercules HC1820PC
Summary of Contents for KING CANOPY Hercules HC1820PC
- Page 1 18ft X 20ft ™ 17ft9in Wide x 20ft Deep x 6ft8in Side Height / 11ft6in Center Height King Canopy Item #: HC1820PC With 8 Legs, White Drawstring Cover, Elastic Ball Straps & Foot Pads. WARNING: Keep all flame and heat sources away from this tent fabric.
- Page 2 PARTS LIST 6X6-2PC 25 pc 78” Pipe 3X2-2PC 8 pc 38” Swedge Pipe 3W2PC 6 pc 3-Way Connectors 4W2PC 6 pc 4-Way Connectors BALL75W 75 pc Elastic Ball Straps FOOT2PC 8 pc Metal Foot Pads TDS1820-5 1 pc White Drawstring Cover CCLIP2 4 pc Curtain Clips...
- Page 3 FRAME ASSEMBLY Step 1 Separate all pieces according to size and shape and arrange per the illustration shown below. Please note: • The 38in (8) and 78” (8) pipes are used to form the roof rafters • The remaining 78in pipes are used to form the roof perimeter and for the legs 78’’...
- Page 4 COVER ASSEMBLY Step 1 Unfold the cover with the grommets toward the cover’s bottom and place over the frame. The flared edges should be located at each of the 4 corners of the frame. Step 2 Begin attaching the cover with the elastic ball straps by inserting the elastic cord of the ball strap underneath the cover and through the grommet.
- Page 5 LEGS ASSEMBLY NOW, CONNECT THE LEG POLES TO THE ROOF ASSEMBLY WITH THE COVER ALREADY POSITIONED ON TOP OF THE UNIT. Insert Second Insert First Step A: First insert the pipes for the middle poles into the 3- and 4-way connectors, and then connect the end leg pipes in the same way.
- Page 6 ANCHORING YOUR UNIT This canopy is designed for use as a temporary structure. After assembly, the canopy MUST BE securely anchored to the ground to prevent damage from winds. Your canopy will act like a kite in the wind if not properly and securely anchored to the ground.
- Page 7 IMPORTANT NOTICE: PLEASE READ CAREFULLY We are confident that you will be completely satisfied with your King Canopy unit. Please take a moment to read the very important information below, and call us with any questions you may have. King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and we are in no way responsible for any damage caused by the canopy or to the canopy.
- Page 8 Improper Anchoring, Strong Winds, Rain Snow, or Ice King Canopy/PIC America, LTD. does not guarantee these canopies under strong weather conditions. These canopies are designed to protect against damages caused by sun, rain, tree sap, birds, etc. They are not designed to hold roof loads that accompany snow, ice or heavy rains.
