KING CANOPY Hercules HC1827PC Assembly Manual

18ft x 27ft
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Hercules
18ft X 27ft
™
17ft9in Wide x 27ft Deep x 6ft8in Side Height /
11ft6in Center Height
King Canopy Item #: HC1827PC
With 10 Legs, White Drawstring Cover,
Elastic Ball Straps & Foot Pads.
WARNING:
Keep all flame and heat sources
away from this tent fabric. Meets
the flammability requirements of
Distributed by:
CPAI-84 Sec 6 and NFPA 701. It is not
PIC America, LTD.
fire proof. The fabric will burn if left in
8009 Purfoy Road • Fuquay-Varina, NC 27526
continuous contact with any flame source.
1-800-800-6296 • www.kingcanopy.com
