KING CANOPY EX1220 Quick Start Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
12ft X 20ft / 20ft x 20ft
10ft3in Center Height (12x20) / 11ft7in Center Height (20x20)
With 8 Legs, Cover with Leg Skirts (12x20 and 20x20), Foot Pads,
Elastic Ball Straps and Center Leg Straps.
Distributed by:
PIC America, LTD.
8009 Purfoy Road • Fuquay-Varina, NC 27526
1-800-800-6296 • www.kingcanopy.com
2-N-1 Expandable
19ft7in Wide x 20ft Deep x
King Canopy Item #: EX1220
™
WARNING:
Keep all flame and heat sources
away from this tent fabric. Meets
the flammability requirements of
CPAI-84 & NFPA 701. It is not fire proof.
The fabric will burn if left in continuous
contact with any flame source.

Advertisement

loading
Need help?

Need help?

Do you have a question about the EX1220 and is the answer not in the manual?

Questions and answers

Related Manuals for KING CANOPY EX1220

Summary of Contents for KING CANOPY EX1220

  • Page 1 12ft X 20ft / 20ft x 20ft 19ft7in Wide x 20ft Deep x 10ft3in Center Height (12x20) / 11ft7in Center Height (20x20) King Canopy Item #: EX1220 With 8 Legs, Cover with Leg Skirts (12x20 and 20x20), Foot Pads, Elastic Ball Straps and Center Leg Straps.

  • Page 2: Parts List

    PARTS LIST 6X3-2PC1 8 pc (A) 77.5” x 2” Pipes 6x3-2PC2 8 pc (B) 77.5” x 2” Double Swedge Pipes 6x6-15PC 9 pc (C) 77.5” x 1.5” Pipes 3x9-2PC 8 pc (D) 45” x 2” Swedge Pipes Used in Roof to Expand to 20ft x 20ft 3W1915PC 6 pc 3-way Connectors...

  • Page 3: Frame Assembly

    FRAME ASSEMBLY Decide which canopy size you would like to assemble, 12ft x 20ft or 20ft x 20ft, and lay out the parts according to the diagrams below. The large diameter pipes are used to form the roof rafter and the small diameter pipes are used to form the length of the canopy.
  • Page 4 PREPARING CovER FoR FRAME Using the diagram below choose the cover parts to assemble the cover to fit the frame size you have assembled. All cover parts are labeled. The A and B labeled sides of top are used with either the 12ft wide or the 20ft wide cover.
  • Page 5 ATTAChING CovER WITh BALL STRAPS Step 1 When the cover has been assembled the leg skirts should be at each corner. The flared leg skirts should be over each of the corner slip-in fittings where the legs will be inserted. (Attachment of these valances will be discussed later).
  • Page 6 LEGS ASSEMBLY NoW, CoNNECT ThE LEG PoLES To ThE RooF ASSEMBLY WITh ThE CovER ALREADY PoSITIoNED oN ToP oF ThE uNIT. (The diagram below illustrate the underside of cover with the grommet holes. The leg valances and A-Frame ends are not shown in illustration.) Step A: First insert the pipes for the middle poles into the 3- and 4-way connectors, and then connect the end leg pipes in the same way.
  • Page 7 ANChoRING YouR uNIT This canopy is designed for use as a temporary structure. After assembly, the canopy MUST BE securely anchored to the ground to prevent damage from winds. Your canopy will act like a kite in the wind if not properly and securely anchored to the ground.
  • Page 8 IMPoRTANT NoTICE: PLEASE READ CAREFuLLY We are confident that you will be completely satisfied with your King Canopy unit. Please take a moment to read the very important information below, and call us with any questions you may have. King Canopy/PIC America, LTD. has no control over wind, snow, ice, rain or any other weather condition and we are in no way responsible for any damage caused by the canopy or to the canopy.

  • Page 9: Product Information

    Improper Anchoring, Strong Winds, Rain Snow, or Ice King Canopy/PIC America, LTD. does not guarantee these canopies under strong weather conditions. These canopies are designed to protect against damages caused by sun, rain, tree sap, birds, etc. They are not designed to hold roof loads that accompany snow, ice or heavy rains.
