INSTALLATION and OPERATION MANUAL
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc. constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
BARNES
BARNES
Submersible Sewage Ejector
®
Series:
3SE-L
(Vertical Discharge)
1.5 & 2HP
1750RPM, 60Hz
3SEH-L
(Horizontal Discharge)
1.5 & 2HP
1750RPM, 60Hz
(Single Seal)
83 West Drive, Brampton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
Form No. 132724-Rev. G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Barnes 3SEH-L and is the answer not in the manual?

Questions and answers

Summary of Contents for Crane Barnes 3SEH-L

  • Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc. constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notification. A Crane Co. Company...
  • Page 2: Table Of Contents

    SEAL TOOL KIT ( see parts list) PRESSURE GAUGE KIT (see parts list) Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc 1994, 2002, 3/06, 9/06 Alteration Rights Reserved...
  • Page 3: Safety First

    IMPORTANT! - Crane Pumps & Systems, Inc. is not CAUTION! Pumps build up heat and pressure responsible for losses, injury, or death resulting from a failure...
  • Page 4: Pump Specifications

    SECTION: A - PUMP SPECIFICATIONS: DISCHARGE ....3” NPT, Vertical SPEED ......1750RPM, 60Hz (nominal) 3” Flanged, Horizontal UPPER BEARING: LIQUID TEMPERATURE .. 104°F (40°C) Continuous 1.5 & 2HP ..Single Row, Ball, Oil Lubricated MOTOR HOUSING ..Cast Iron ASTM, Class 30 Load .....
  • Page 5: General Information

    For the location of the nearest Barnes Service Center, check the rails are in a true vertical position so the pump will clear your Barnes representative or Crane Pumps & Systems, Inc., the access opening and will slide freely down the rails into Service Department in Piqua, Ohio, telephone (937) 778-8947 place on the discharge stationary fitting.
  • Page 6: Start-Up Operation

    C-4) Electrical Connections: C-4.4) Wire Size: C-4.1) Power Cable: Consult a qualified electrician for proper wire size if additional The cord assembly mounted to the pump must not be modified power cable length is required. See table for electrical in any way except for shortening to a specific application. information.
  • Page 8: Service And Repair

    1) Inspect motor chamber for oil level and contamination and pressure and remove the gauge assembly. If the pressure repair as required per paragraph F-1. does not hold, then the leak must be located and repaired. 2) Inspect impeller and body for excessive build-up or clogging and repair as required per paragraph F-2.
  • Page 9 F-2) Impeller and Volute Service: and lift motor stator from seal plate (1). Disconnect capacitor F-2.1) Disassembly and Inspection: leads from capacitor (21, single phase units). Examine To clean out volute (24) or replace impeller (29), disconnect bearing (6) and replace if required. If replacement is required, power, remove screws (12), and lockwashers (11), vertically remove bearing (6) from motor shaft using a wheel puller or lift motor and seal plate assembly from volute (24).
  • Page 10 POWER CORD (30) CONTROL CORD (32) CAP SCREW (16) CAP SCREW (16) LOCKWASHER (11) LOCKWASHER (11) COMPRESSION FLANGE (30a) COMPRESSION FLANGE (32a) SNAP RING (41) SNAP RING (41) O-RING (40) O-RING (40) TERMINAL BLOCK (23) TERMINAL BLOCK (38) TERMINAL TERMINAL FIGURE 5 Motor - Slide lower bearing (6) and motor shaft squarely Reconnect motor and optional control leads to the underside...
  • Page 11 Stationary Member (31A) Motor & Bearing Bracket Rotating Member (31B) Polished Face Out Stationary Seal Plate (1) Seal Pusher Seal Pusher Bullet FIGURE 8 FIGURE 7 Important ! - DO NOT Hammer On The Seal DO NOT interchange seal components, replace the entire Pusher- It Will Damage The Seal Face.
  • Page 12: Replacement Parts

    SECTION: G REPLACEMENT PARTS G-2 PART NUMBER: The part number consists of a six (6) digit number, which appears in the catalog. A one or two letter suffix may follow this G-1 ORDERING REPLACEMENT PARTS: number to designate the design configuration. This number is When ordering replacement parts, ALWAYS furnish the used for ordering and obtaining information.
  • Page 13 FIGURE 10...
  • Page 14: Trouble Shooting

    TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”...
  • Page 15: Cross-Section (Figure 11A & 11B)

    CROSS SECTION (VERTICAL DISCHARGE) OPTIONAL TEMPERATURE SENSOR CABLE ASSEMBLY FIGURE 11a...
  • Page 16 CROSS SECTION (HORIZONTAL DISCHARGE) OPTIONAL TEMPERATURE SENSOR CABLE ASSEMBLY FIGURE 11b...
  • Page 17: Exploded View (Figure 12)

    EXPLODED VIEW FIGURE 12...
  • Page 18: Parts List

    PARTS KITS SEAL REPAIR KIT: 1.5 & 2.0HP.... P/N 130181 (+) 8, 10, 31, 40 SERVICE: 1.5 & 2.0HP ......P/N 130208 (◊) 2, 3, 6, 8, 10, 14, 15, 18, 25, 31, 34, 35, 40, 41 TOOLS: Seal Pusher......P/N- TL-21360 Bullet ........
  • Page 19 TABLE 2 - POWER & SENSOR CORD SETS TERMINAL BLOCK MODEL NO 30 FT. POWER 50 FT. POWER 100 FT. POWER POWER 3SE1524L 109498XC 109498XF 109498XL 103760 3SE1594L 109492XC 109492XF 109492XL 103586 3SE1544L 103742XC 103742XF 103742XL 103583 3SE1554L 103742XC 103742XF 103742XL 103583 3SE2024L...
  • Page 20 Notes...
  • Page 21: Warranty

    IMPORTANT! WARRANTY REGISTRATION Your product is covered by a warranty: www.cranepumps.com/downloadables/CATALOGS_OIPMs/Warranty/24MonthWarranty.pdf If you have a claim under the provisions of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor.
