INSTALLATION and OPERATION MANUAL
IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notification.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
BARNES
BARNES
Submersible Sewage Ejector
83 West Drive, Brampton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
®
Series:
3SE-L, 3HP
(Vertical Discharge)
3450RPM, 60Hz
3SE-L, 3HP
(Vertical Discharge)
1750RPM, 60Hz.
3SEH-L, 3HP
(Horizontal Discharge)
3450RPM, 60Hz
3SEH-L, 3HP
(Horizontal Discharge)
1750RPM, 60Hz.
(Single Seal)
Form No. 133410-Rev. H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BARNES 3SE-L and is the answer not in the manual?

Questions and answers

Related Manuals for Crane BARNES 3SE-L

Summary of Contents for Crane BARNES 3SE-L

  • Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notification. A Crane Co. Company...

  • Page 2: Table Of Contents

    PRESSURE GAUGE KIT (see parts list) Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc 1996, 1997, 1998, 2001, 2002, 3/06, 9/06, 2/07...

  • Page 3: Safety First

    WARNING! - DO NOT pump hazardous materials IMPORTANT! - Crane Pumps & Systems, Inc. is not (flammable, caustic, etc.) unless the pump is specifically responsible for losses, injury, or death resulting from a designed and designated to handle them.

  • Page 4: Pump Specifications

    SECTION: A - PUMP SPECIFICATIONS: 3450RPM DISCHARGE ....3” NPT, Vertical SPEED ......3450RPM, 60Hz (nominal) 3” Flanged, Horizontal UPPER BEARING: ..Single Row, Ball, Oil Lubricated LIQUID TEMPERATURE . 104°F (40°C) Continuous Load ..... Radial MOTOR HOUSING ..Cast Iron ASTM A-48, Class 30 LOWER BEARING: VOLUTE ......
  • Page 5 SECTION: A - PUMP SPECIFICATIONS: 1750RPM DISCHARGE ....3” NPT, Vertical SPEED ......1750RPM, 60Hz (nominal) 3” Flanged, Horizontal UPPER BEARING: LIQUID TEMPERATURE . 104°F (40°C) Continuous Design ..Single Row, Ball, Oil Lubricated MOTOR HOUSING ..Cast Iron ASTM A-48, Class 30 Load .....

  • Page 6: General Information

    For the location of the nearest CP&S Service Center, check position so the pump will clear the access opening and your CP&S representative or Crane Pumps & Systems, Inc., will slide freely down the rails into place on the discharge Service Department in Piqua, Ohio, telephone (937) 778-8947 stationary fitting.

  • Page 7: Electrical Data

    C-4) Electrical Connections: SECTION: D START-UP OPERATION C-4.1) Power Cord: D-1) Check Voltage and Phase: The cord assembly mounted to the pump must not be modi- Before operating pump, compare the voltage and phase fied in any way except for shortening to a specific application. information stamped on the pump identification plate to the Any splice between the pump and the control panel must be available power.

  • Page 9: Preventative Maintenance

    SECTION E: PREVENTATIVE MAINTENANCE TABLE 1 - COOLING OIL - Dielectric As the motor is oil filled, no lubrication or other maintenance SUPPLIER GRADE is required, and generally CP&S pumps will give very reliable Sohio / Standard SE 40, Energol HL22 or HL32 service and can be expected to operate for years on normal Shell Turbo Oil 32...
  • Page 10 MOTOR END (INBOARD END) CONDUIT BUSHING (14) Retaining Ring (30) Ball Bearing (47) WASHER (9) RETAINING RING (46D) SPRING (46C) SEAL ASSEMBLY (46) ROTATING MEMBER (46B) SEAL PLATE (25) STATIONARY (46A) EXCLUSION SEAL (17) PULL WASHER (16) FIGURE 3 PUMP END (OUTBOARD END) Caution! - Pressure builds up extremely fast, increase pressure by “tapping”...
  • Page 11 F-3.2) Reassembly: Position unit upright, using blocks to avoid resting unit on shaft. Unscrew cord hex bolts (6) and remove compression Bearing - When replacing bearing, be careful not to damage flange (10a) and power cord (10). Remove snap ring (8) with the rotor or shaft threads.

  • Page 12: Replacement Parts

    Place all motor leads above motor. Position square ring (42) F-3.4) Cord Assemblies: Power - Refill the cooling oil as outlined in paragraph F-1.4. on seal plate (25) and lower motor housing (2) over motor and into pilot. Place socket head cap screws (39) through Make wire connections as outlined in paragraph F-3.3.

  • Page 13: Wiring Schematics

    FIGURE 10...

  • Page 14: Trouble Shooting

    TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”...

  • Page 15: Cross-Section 3Se-L 3450Rpm (Fig. 9)

    CROSS SECTION - 3SE-L 3450RPM VERTICAL DISCHARGE) OPTIONAL SENSOR CABLE ASSEMBLY OPTIONAL SENSOR TERMINAL BLOCK OIL LEVEL FIGURE 11a...
  • Page 16 CROSS SECTION - 3SE-L 3450RPM HORIZONTAL DISCHARGE) OPTIONAL SENSOR CABLE ASSEMBLY OPTIONAL SENSOR TERMINAL BLOCK OIL LEVEL FIGURE 11b...

  • Page 17: Exploded View 3Se-L 3450Rpm (Fig. 10)

    EXPLODED VIEW - 3SE-L 3450RPM 24 43 FIGURE 12...

  • Page 18: Parts List 3Se-L 3450Rpm

    3SE-L 3450RPM Pump Series PARTS KITS Seal Repair Kit ..P/N - 130182 (†) 12, 16, 17, 42, 46 Overhaul Kit ..P/N - 130209 (♦) 8, 12, 16, 17, 30, 33, 34, 35, 42, 46, 47 PARTS LIST ITEM PART NO.
  • Page 19 3SE-L 3450RPM Pump Series PARTS LIST ITEM PART NO. DESCRIPTION NOTES 11-32-1 SKHD Cap Screw 1/4-20 x 1.00” LG, SS 033730 †♦ Square Ring Buna-N ------- Loctite Adhesive, #242-41 Blue ------- Loctite Adhesive, #RC603 Green ------- Loctite PSP #567 White Pipe Sealant 062435 †♦...

  • Page 20: Cross-Section 3Se-L 1750Rpm (Fig. 11A & 11B)

    CROSS SECTION - 3SE-L 1750RPM VERTICAL DISCHARGE) OPTIONAL SENSOR CABLE ASSEMBLY OPTIONAL SENSOR TERMNAL BLOCK OIL LEVEL FIGURE 13a...
  • Page 21 CROSS SECTION - 3SE-L 1750RPM HORIZONTAL DISCHARGE) OPTIONAL SENSOR CABLE ASSEMBLY OPTIONAL SENSOR TERMNAL BLOCK OIL LEVEL FIGURE 13b...

  • Page 22: Exploded View 3Se-L 1750Rpm (Fig. 12)

    EXPLODED VIEW - 3SE-L 1750RPM FIGURE 14...

  • Page 23: Parts List 3Se-L 1750Rpm

    3SE-L 1750RPM Pump Series PARTS KITS Seal Repair Kits Single Seal..P/N - 130182 (†) 12, 16, 17, 42, 46 Service Kits Single Seal..P/N - 130209 (♦) 8, 12, 16, 17, 30, 33, 34, 35, 42, 46, 47 PARTS LIST ITEM PART NO.
  • Page 24 3SE-L 1750RPM Pump Series PARTS LIST ITEM PART NO. DESCRIPTION NOTES 088534TM 6.00” Dia. 088534TN 5.88” Dia. 088534TP 5.75” Dia. 088534TQ 5.62” Dia. 105149A Jumper Wire 230V, 3 Phase 057882 ♦ Retaining Ring 035589 ♦ Shaft Key #61 x .187 038132 ♦...
  • Page 25 Notes...
  • Page 26 Notes...

  • Page 27: Warranty

    IMPORTANT! WARRANTY REGISTRATION Your product is covered by a warranty: www.cranepumps.com/downloadables/CATALOGS_OIPMs/Warranty/24MonthWarranty.pdf If you have a claim under the provisions of the warranty, contact your local Crane Pumps & Systems, Inc. Distributor.

This manual is also suitable for:

Barnes 3seh-l
