IMPORTANT!
Read all instructions in this manual before operating pump.
As a result of Crane Pumps & Systems, Inc., constant product improvement program,
product changes may occur. As such Crane Pumps & Systems reserves the right to
change product without prior written notifi cation.
A Crane Co. Company
420 Third Street
Piqua, Ohio 45356
Phone: (937) 778-8947
Fax: (937) 773-7157
www.cranepumps.com
Manual Index
BARNES
INSTALLATION MANUAL
Submersible Sewage Pump
®
Series: 3SE-HD
(Heavy Duty)
1.5 & 2HP, 1750RPM
83 West Drive, Brampton
Ontario, Canada L6T 2J6
Phone: (905) 457-6223
Fax: (905) 457-2650
Form No. 133460-Rev. A
Advertisement
Table of Contents
Related Manuals for Crane Barnes 3SE-HD Series
Summary of Contents for Crane Barnes 3SE-HD Series
- Page 1 Read all instructions in this manual before operating pump. As a result of Crane Pumps & Systems, Inc., constant product improvement program, product changes may occur. As such Crane Pumps & Systems reserves the right to change product without prior written notifi cation.
-
Page 2: Table Of Contents
PRESSURE GAUGE KIT (see parts list) Other brand and product names are trademarks or registered trademarks of their respective holders. ® Barnes is a registered trademark of Crane Pumps & Systems, Inc. 1999, 2002, 7/2004, 4/06, 6/06, 9/06 Alteration Rights Reserved... -
Page 3: Safety First
Crane Pumps & Systems, Inc. is not responsible WARNING ! Do not pump hazardous materials for losses, injury, or death resulting from a failure to (fl... -
Page 4: Pump Specifications
SECTION: A - PUMP SPECIFICATIONS: DISCHARGE ....3” NPT, Vertical SPEED ......1750 RPM, 60Hz (nominal) LIQUID TEMPERATURE 104°F (40°C) Continuous UPPER BEARING: MOTOR HOUSING ..Cast Iron ASTM A-48, Class 30 Design ..Single Row, Ball, Oil Lubricated VOLUTE ......Cast Iron ASTM, Class 30 Load ..... -
Page 5: General Information
Service Department in Piqua, Ohio, telephone (937) 778-8947 Any splice between the pump and the control panel must be or Crane Pumps & Systems Canada, in Brampton, Ontario, made in accordance with all applicable electric codes. It is (905) 457-6223. -
Page 6: Start-Up Operation
C-3.2) Overload Protection Single Phase - SECTION E: PREVENTATIVE MAINTENANCE The type of in-winding overload protector used is referred to as an inherent overheating protector and operates on the As the motor is oil fi lled, no lubrication or other maintenance combined effect of temperature and current. - Page 8 CAUTION ! - Pressure builds up extremely TABLE 1 - COOLING OIL - Dielectric fast, increase pressure by “tapping” air SUPPLIER GRADE nozzle. Too much pressure will damage Sohio / Standard SE 40, Energol HL22 or HL32 seal. DO NOT exceed 10 P.S.I. in motor Shell Turbo Oil 32 housing...
- Page 9 Check motor capacitor (3, 1 phase units) with an Ohm meter by fi rst grounding the capacitor by placing a screwdriver across both terminals and then removing screwdriver. Connect Ohm meter (set on high scale) to terminals. If needle moves to infi nity (∞) then drifts back, the capacitor is good.
- Page 10 Seal - Clean and oil seal cavity in seal plate (24). Press sta- tionary member (38a) fi rmly into seal plate (24), using a seal pusher, nothing but the seal pusher is to come in contact with seal face (See Figure 6). Make sure the stationary member is in straight.
-
Page 11: Replacement Parts
F-3.4) Cord Assemblies: G-2 PART NUMBER: The part number consists of a six (6) digit number, which appears Power - Refi ll the cooling oil as outlined in paragraph F-1.3. in the catalog. A one or two letter suffi x may follow this number Make wire connections as outlined in paragraph F-3.3. -
Page 12: Wire Schematics
FIGURE 10... -
Page 13: Trouble Shooting
TROUBLE SHOOTING CAUTION ! Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. If operating problems persist, the following chart may be of assistance in identifying and correcting them: MATCH “CAUSE”... -
Page 14: Cross-Section (Figure. 11)
FIGURE 11... -
Page 15: Exploded View (Figure. 12)
FIGURE 12... -
Page 16: Parts List
PARTS KITS Seal Repair Kit ....P/N - 130182 ) 9, 36, 38, 40, 41 † Service Kit ......P/N - 130209 (♦) 8, 9, 11, 17, 29, 32, 33, 36, 38, 39, 40, 41 PARTS LIST ITEM PART NO. DESCRIPTION NOTES 053284 Motor, 3SE1524HD, 3SE2024HD 230V, 1 Phase, 1750RPM... - Page 17 PARTS LIST ITEM PART NO. DESCRIPTION NOTES 108051 Gasket Shaft Seal 062435 ♦ Mechanical Shaft Seal Carbon/Ceramic/Buna-N (STD) † 062435SB Mechanical Shaft Seal Tungsten/Tungsten/Buna-N 062435SD Mechanical Shaft Seal Silicon/Silicon/Buna-N 053746 ♦ Ball Bearing 062641 ♦ Pull Washer † 061829 ♦ Exclusion Seal Buna-N †...
-
Page 18: Warranty
Limited 24 Month Warranty Crane Pumps & Systems warrants that products of our manufacture will be free of defects in material and workmanship under normal use and service for twenty-four (24) months after manufacture date, when installed and maintained in accordance with our instructions.This warranty gives you specifi c legal rights, and there may also be other rights which vary from state to state. -
Page 19: Returned Goods Policy
Crane Pumps & Systems, Inc. Distributor. RETURNED GOODS RETURN OF MERCHANDISE REQUIRES A “RETURNED GOODS AUTHORIZATION”. CONTACT YOUR LOCAL CRANE PUMPS & SYSTEMS, INC. DISTRIBUTOR. Products Returned Must Be Cleaned, Sanitized, Or Decontaminated As Necessary Prior To Shipment, To Insure That Employees Will Not Be Exposed To Health Hazards In Handling Said Material. - Page 20 Notes...
