- Page 1 ELECTRIC IMPACT WRENCH MODEL NO: CEW520 PART NO: 6480280 OPERATION & MAINTENANCE INSTRUCTIONS LS0519 - ISS 1 ORIGINAL INSTRUCTIONS...
- Page 2 INTRODUCTION Thank you for selecting this Clarke impact wrench. The impact wrench is intended for tightening and loosening nuts, and is equipped with a rotary impact mechanism. IMPORTANT Read all instructions carefully before you use this impact wrench. Pay attention to all sections of this user guide that display warning symbols and notices.
-
Page 3: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS WARNING: READ ALL SAFETY WARNINGS AND ALL INSTRUCTIONS. FAILURE TO FOLLOW THE WARNINGS AND INSTRUCTIONS MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR SERIOUS INJURY. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated impact wrench. -
Page 4: Personal Safety
PERSONAL SAFETY 1. Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. -
Page 5: Safety Symbols
4. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. 5. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS FULLY BEFORE CONNECTING THE IMPACT WRENCH TO THE MAINS SUPPLY. This impact wrench is provided with a standard 13 amp, 230 volt (50Hz), BS 1363 plug, for connection to a standard, domestic electrical supply. Should the plug need changing, make sure that a plug of identical specification is used. - Page 7 OVERVIEW 1/2” Square Drive Mains Cable Body Direction Switch Trigger Sockets (17, 19, 21 & 22 mm) Case ONLY SPECIAL SOCKETS THAT ARE DESIGNED FOR IMPACT TOOLS SHOULD BE USED WITH THIS IMPACT WRENCH. STANDARD SOCKETS MAY SHATTER. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 8: Attach / Remove A Socket
OPERATING INSTRUCTIONS WARNING: ALWAYS MAKE SURE THAT THE IMPACT WRENCH IS DISCONNECTED FROM THE POWER SUPPLY BEFORE CHANGING THE SOCKET. ATTACH / REMOVE A SOCKET CAUTION: MAKE SURE THAT THE CORRECT SOCKET IS BEING USED. AN INCORRECT SOCKET IS LIKELY TO DAMAGE THE HEADS OF THE BOLTS OR NUTS. -
Page 9: Loosening A Nut
GENERAL MAINTENANCE 1. Refer to your CLARKE dealer if internal maintenance is necessary. 2. Make sure that the power cable is free from cracks, bare wires etc. 3. If it is necessary to replace the power cable, this must be done by the manufacturer. -
Page 10: Environmental Protection
In effect, this means that this tool must not be discarded with general waste. Refer to the laws governing Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal facility. SPECIFICATIONS Model CEW520 Voltage 230v / 50 Hz Rated Input Power 520 W... -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
