- Page 1 AIR IMPACT WRENCH MODEL NO: CAT131 & 132 PART NO: 3120145 / 3120146 OPERATING & MAINTENANCE INSTRUCTIONS GC0414...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Impact Wrench. The CAT131 and CAT132 are identical wrenches, the CAT132 being supplied in a moulded plastic storage case which contains the following: • 1 x Mini-Oiler • 1 x Extension Bar • 1 x Hex Key •...
-
Page 3: General Safety Rules
GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way. - Page 4 • Moving to another work area. • Passing the tool to another person. 13. Never use the tool if it is defective or operating abnormally. 14. This tool should be serviced at regular intervals by qualified personnel. 15. Avoid damaging the tool for example by applying excessive force of any kind.
-
Page 5: Transport And Storage
10. Always store this product in a dry, secure place out of reach of children or untrained users. 11. Always use both hands to control the impact wrench. 12. Always ensure the wrench has stopped before putting it down after use. TRANSPORT &... -
Page 6: Compressed Air Requirements
• A typical air line layout is shown above. If an automatic in-line filter/ regulator is used, it will keep the tool in good condition, but should be regularly checked and topped up with oil. clarke airline oil should be used, and the lubricator adjusted to approx 2 drops per minute. -
Page 7: Before Use
• PTFE tape may be useful for sealing threaded connections. Your air tool is now ready for use. You can fit a whip hose with a quick fit coupling if required, available from your Clarke dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 8: Operation
OPERATION WARNING: WAIT UNTIL THE ANVIL HAS STOPPED ROTATING BEFORE OPERATING THE FORWARD/REVERSE BUTTON. Forward/Reverse rotation is selected by pushing the combined Forward/ Reverse knob/power regulator in the direction shown by the arrow on the back of the wrench. 1. For normal tightening, the wrench should be operated in the forward (F) direction. -
Page 9: Operating The Impact Wrench
OPERATING THE IMPACT WRENCH 1. Locate the socket over the nut to be tightened or loosened. 2. Squeeze the trigger to start the wrench. 3. Release the trigger switch to stop the wrench. • The square drive shaft will continue to rotate very briefly after the trigger has been released. -
Page 10: Maintenance
1. Before use, drain water from the airline filter and compressor. 2. Pour a few drops of Clarke air-line oil, into the tool air inlet. This should be carried out regardless of whether or not an in-line mini oiler is used. If an in- line mini oiler is not used, this procedure should be repeated after every two to three hours of use. -
Page 11: Troubleshooting
**Clarke Air Line Oil (part no. 3050825) is available from your Clarke dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 12: Specification
If the tool is to be stored, or is idle for longer than 24 hours, run a few drops of Clarke air line oil into the air inlet, and run the tool for 5 seconds in order to lubricate the internal parts. -
Page 13: Parts List
A wide range of accessories is available including filter/regulators, lubricators, high-pressure hoses (5 to 50 metres) etc. Contact your Clarke dealer for further information or the Clarke International Service Department. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
