20V CORDLESS IMPACT DRIVER
MODEL NO: CID20Li
PART NO: 6487000
OPERATION & MAINTENANCE
INSTRUCTIONS
LS0213

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CID20Li and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke CID20Li

  • Page 1 20V CORDLESS IMPACT DRIVER MODEL NO: CID20Li PART NO: 6487000 OPERATION & MAINTENANCE INSTRUCTIONS LS0213...
  • Page 2 INTRODUCTION Thank you for purchasing this CLARKE 20V Cordless Impact Driver. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN ALL WARNINGS LISTED BELOW REFERS TO YOUR 20V CORDLESS IMPACT DRIVER. 1) WORK AREA SAFETY a.
  • Page 4 c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d.
  • Page 5: Safety Instructions For All Impact Drivers

    c. When battery pack is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
  • Page 6 SYMBOLS Weee Symbol CE Mark Read instruction manual before use Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 7: Before Use

    BEFORE USE FITTING THE BATTERY PACK (NOT SUPPLIED) This impact driver requires a 20V battery pack (6487040) and 1 Hour Charger (6487050) to operate. Both are available separately from your local Clarke dealer. TO FIT THE BATTERY 1. Slide the battery pack onto the base of the impact driver.
  • Page 8: Fitting The Impact Bits

    FITTING THE IMPACT BITS WARNING: BEFORE FITTING OR REMOVING ANY IMPACT BITS MAKE SURE THAT THE FORWARD/REVERSE SWITCH IS IN THE CENTRAL LOCKED OFF POSITION. NOTE: The chuck accepts 1/4" (6.35 mm) hex accessories. TO INSTALL AN ACCESSORY, 1. Pull the chuck collar away from the front of the tool. 2.
  • Page 9: Maintenance And Servicing

    • Refer to your CLARKE dealer if internal maintenance is required. • Your Clarke impact driver has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local Clarke dealer.
  • Page 10: Specifications

    SPECIFICATIONS MODEL CID20L Voltage 20 V DC Drive Size 1/4” (6.35 mm) Hexagonal Maximum Torque 160 Nm Impact Rate 0-2800 Blows Per Minute No Load Speed 2300 RPM Weight (without battery pack) 1.2 kg Dimensions (without battery pack) (L x W x H) 210 x 70 x 197 mm Sound Pressure Level (LPA) 90.2 dB(A)
  • Page 11: Declaration Of Conformity

    DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
