BUTTERFLY IMPACT WRENCH
3/8"
MODEL NO: CAT64
PART NO: 3110720
OPERATING & MAINTENANCE
INSTRUCTIONS
GC0414

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAT64 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke CAT64

  • Page 1 BUTTERFLY IMPACT WRENCH 3/8” MODEL NO: CAT64 PART NO: 3110720 OPERATING & MAINTENANCE INSTRUCTIONS GC0414...
  • Page 2 INTRODUCTION Thank you for purchasing this CLARKE Impact Wrench. The CAT64 is a compact and lightweight unit which allows one-handed control for forward and reverse operation. IMPORTANT Please read all of the safety and operating instructions carefully before using this product. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
  • Page 3: General Safety Rules

    GENERAL SAFETY RULES CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT 1. Keep the work area clean and tidy. 2. Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way.
  • Page 4 • Moving to another work area. • Passing the tool to another person. 13. Never use the tool if it is defective or operating abnormally. 14. This tool should be serviced at regular intervals by qualified personnel. 15. Avoid damaging the tool for example by applying excessive force of any kind.
  • Page 5: Transport And Storage

    10. Always store this product in a dry, secure place out of reach of children or untrained users. 11. Always use both hands to control the impact wrench. 12. Always ensure the wrench has stopped before putting it down after use. TRANSPORT &...
  • Page 6: Compressed Air Requirements

    • A typical air line layout is shown above. If an automatic in-line filter/ regulator is used, it will keep the tool in good condition, but should be regularly checked and topped up with oil. clarke airline oil should be used, and the lubricator adjusted to approx 2 drops per minute.
  • Page 7: Before Use

    • PTFE tape may be useful for sealing threaded connections. Your air tool is now ready for use. You can fit a whip hose with a quick fit coupling if required, available from your Clarke dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 8: Operation

    OPERATION WARNING: NEVER USE STANDARD SOCKETS. THESE MAY SHATTER WITH SERIOUS CONSEQUENCES. ONLY USE IMPACT SOCKETS DESIGNED FOR USE WITH IMPACT TOOLS. FITTING THE IMPACT SOCKET 1. Select the impact socket you require, which must be in good condition and fit the tool exactly. 2.
  • Page 9: Adjusting The Power

    ADJUSTING THE POWER 1. To adjust the power, set the air regulator to one of the 8 settings available. (Setting 1-Low, 8 -High) • These numbers are only for reference and do not denote a specific amount of power. For maximum power when removing stubborn nuts, turn the supply regulator to its highest setting.
  • Page 10: Maintenance

    1. Before use, drain water from the airline filter and compressor. 2. Pour a few drops of Clarke air-line oil, into the tool air inlet. This should be carried out regardless of whether or not an in-line mini oiler is used. If an in- line mini oiler is not used, this procedure should be repeated after every two to three hours of use, or at the start of the working day.
  • Page 11: Troubleshooting

    **Clarke Air Line Oil (part no. 3050825) is available from your Clarke dealer. Your Clarke air tool has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local Clarke dealer.
  • Page 12: Specification

    Weight(s) 0.9 kg Please note that the details and specifications contained herein are correct at the time of going to print. However Clarke International reserve the right to change specifications at any time without prior notice. ACCESSORIES A wide range of accessories is available including filter/regulators, lubricators, high-pressure hoses (5 to 50 metres) etc.
  • Page 13: Parts List

    PARTS LIST Description No Description Main Housing Rear Cap Gasket Nose Bushing Ball Bearing Oil Seal Rear End Plate Rubber Nose Guard Rotor Throttle Lever Throttle Pin Rotor Blade Oiler Screw Cylinder O-Ring Motor Pin Back Cap Front End Plate Air Inlet Block Oil Seal O-Ring...
  • Page 14: Parts Diagram

    PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 15: Declaration Of Conformity

    DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
