1/2" IMPACT WRENCH
1/2" IMPACT WRENCH
MODEL No: CAT101
Part No: 3110857
OPERATION & MAINTENANCE
INSTRUCTIONS
0707

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAT101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke CAT101

  • Page 1 1/2” IMPACT WRENCH 1/2” IMPACT WRENCH MODEL No: CAT101 Part No: 3110857 OPERATION & MAINTENANCE INSTRUCTIONS 0707...
  • Page 2: Specifications

    Always consult the machine’s data plate GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS IMPORTANT FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. WORK ENVIRONMENT • Keep the work area clean and tidy. • Dress appropriately - Do not wear loose clothing or jewellery. Tie long hair out of the way.
  • Page 4 SAFETY PRECAUTIONS • Always disconnect from the air supply when: Performing any maintenance The impact wrench is not in use. The impact wrench will be left unattended. Moving to another work area. Passing the impact wrench to another person. • Never use the impact wrench if it is defective or operating abnormally.
  • Page 5: Air Supply

    PARTS Anvil Direction Selector Trigger Air Inlet Air Regulator AIR SUPPLY WARNING! COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE THOROUGHLY FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY. • Use only clean, dry, regulated compressed air as a power source for the impact wrench.
  • Page 6: Recommended Air Supply Connection

    Your impact wrench is now ready for use. You can fit a whip hose with a quick fit coupling if required (available from your Clarke dealer.) WARNING! COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU ARE THOROUGHLY FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE USE OF COMPRESSORS AND...
  • Page 7: Fitting The Impact Socket

    OPERATING INSTRUCTIONS WARNING! WAIT UNTIL THE ANVIL HAS STOPPED ROTATING BEFORE OPERATING THE DIRECTION CONTROL SWITCH. USING THE DIRECTIONAL CONTROL BUTTON The direction control button should be used as follows. For normal tightening, the impact wrench should be operated in the forward (F) direction.
  • Page 8: Adjusting The Power

    OPERATING INSTRUCTIONS ADJUSTING THE POWER To adjust the power, set the air regulator to one of the 4 settings avalaible. 1 (Low) - 4 (High). Air Regulator OPERATING THE IMPACT WRENCH Locate the socket over the nut to be tightened or loosened.
  • Page 9: Maintenance

    Drain water from air tank, air line and compressor. • Pour a few drops of CLARKE Air Line Oil, into the air inlet. This should be carried out regardless of whether or not an air line lubricator is used. If an Air line lubricator is not used, this procedure should be repeated after every two to three hours of use.
  • Page 10: Parts Diagram

    PARTS DIAGRAM PARTS LIST Index Part Description Index Part Description KL504W24 Cylinder KL504W01 Housing KL504W02 Valve Bushing KL504W25 Rotor KL504W26 Rotor Blade KL504W03 Reverse Valve KL504W04 Trigger KL504W27 Rear End Plate KLCA6001 Ball Bearing KLSP007 KL504W06 Valve Stem KL504W29 Front End Plate KLSP006 KL504W07 Air Inlet...
  • Page 11: Hand-Arm Vibration

    HAND-ARM VIBRATION Employers are advised to refer to the HSE publication “Guide for Employers”. All hand held power tools vibrate to some extent, and this vibration is transmitted to the operator via the handle, or hand used to steady the tool. Vibration from about 2 to 1500 herz is potentially damaging and is most hazardous in the range from about 5 to 20 herz.
